▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403-CR-E4-GL2 V1903-A Engine Type Naturally aspirated, multi-valve, liquid-cooled diesel Indirect injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 4 4 Displacement 148.5 in³ 113.3 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 42 hp 38.5 hp PTO Power 32.5 hp 31 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry paper, dual element Not Published Fuel System Electronic CRS (Common Rail System) Indirect injection Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Tandem pump - gear type Not Published Implement Flow 9.4 gpm 7.8 gpm Steering Flow 4.7 gpm Not Published Total Hydraulic Flow 14.1 gpm Not Published Overall Hydraulic Pump Flow 14.1 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard (up to 3 optional) Not Published No. of Optional Remote Valves Optional, up to 3: double-acting valve or float detent valve, any position Not Published ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 9.2 gal Coolant Capacity 7.9 qt 7.9 qt Crankcase Capacity 8.7 qt 6.3 qt Transmission / Hydraulic System Capacity 11.4 gal 10.3 gal Front Axle Fluid Capacity 6.9 qt Not Published ▶ PTO & HitchPTO Type Live independent (hydraulic clutch) Independent PTO Rear 540 rpm @ 2476 engine rpm 540 rpm Mid-PTO Availability Optional Optional mid-PTO, 2000 rpm (USA No. 5, Kubota 10-tooth involute spline) Category, 3-Point Hitch SAE Category I Category I Hitch Lift Capacity 3,858 lb 2,870 lb Hitch Lift Capacity (at 24”) 2,760 lb 2,310 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic F (2WD), DT (4WD): synchronized shuttle and synchronized transmission, 8F/8R; GST (4WD): Glide Shift, 8F/8R No. of Speeds 3-Range, 6 speeds (H-DS), infinitely variable in each 8F/8R Max Travel Speed (Forward) 16.8 mph 14.3 mph Max Travel Speed (Reverse) 15.1 mph 13.1 mph Clutch Not Published Dry type single stage Differential Lock & Limited Slip Options Rear differential lock, standard Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post ROPS Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc type, mechanically activated Wet disc type Seat Suspension & Adjustability Deluxe suspension seat with swivel (standard); Air-Ride seat (optional) Not Published Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,433 lb 1,430 lb ▶ Dimensions & ManeuverabilityOverall Width 66.5 in 56.1 in Wheelbase 74.6 in F (2WD): 71.3 in; DT (4WD), GST (4WD): 71.1 in Ground Clearance 14.2 in 13.2 in Min. Turn Radius without Brakes 8.9 ft (with brake applied) F (2WD), DT (4WD): 8.2 ft; GST (4WD): 8.5 ft (with brake applied) Height to Top of ROPS 97.6 in 83.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model n/a (ROPS model) Not Published Overall Length 129.5 in (with 3-point hitch) 118.1 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 3,759 lb F (2WD): 2,800 lb; DT (4WD): 2,955 lb; GST (4WD): 2,965 lb (with ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial Ag: 6.00-16 (2WD) or 8.3-16 (4WD) front, 13.6-24 rear R1 Agricultural - Front 8.3-16 F (2WD): 6.00-16; DT (4WD), GST (4WD): 8.3-16 R1 Agricultural - Rear 14.9-24 13.6-24 R3 Turf - Front 27-10.50LL15 Not Published R3 Turf - Rear 41-18LLx16.1 Not Published R4 Industrial - Front 10-16.5 Not Published R4 Industrial - Rear 17.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Not Published Loader Model LA805 LA680; LA681 Loader Lift Height 104.7 in (at pivot pin) LA680: 102.4 in; LA681: 102.4 in Loader Lift Capacity (Full Height) 1,715 lb (at pivot pin) LA680: 1,499 lb; LA681: 1,499 lb Loader Breakout Force 2,549 lb LA680: 2,557 lbf; LA681: 2,557 lbf ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
