▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403-CR-E4-GL2 V1505-CR-TE5-D40R4 Engine Type Naturally aspirated, multi-valve, liquid-cooled diesel Turbocharged, direct injection, liquid-cooled diesel No. of Cylinders 4 4 Displacement 148.5 in³ 91.4 in³ Rated Engine Speed 2600 rpm 2700 rpm Engine Power (Gross) 42 hp 39.8 hp PTO Power 32.5 hp 32.6 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Pressurized radiator Air Cleaner Dry paper, dual element 6 in paper filter (with dual element) Fuel System Electronic CRS (Common Rail System) Direct injection Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Tandem pump - gear type Dual pump Implement Flow 9.4 gpm 5.4 gpm Steering Flow 4.7 gpm 4.1 gpm Total Hydraulic Flow 14.1 gpm 9.5 gpm Overall Hydraulic Pump Flow 14.1 gpm 9.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard (up to 3 optional) None No. of Optional Remote Valves Optional, up to 3: double-acting valve or float detent valve, any position Optional, up to 2 ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 8.5 gal Coolant Capacity 7.9 qt 4.5 qt Crankcase Capacity 8.7 qt 5.0 qt Transmission / Hydraulic System Capacity 11.4 gal 5.5 gal Front Axle Fluid Capacity 6.9 qt 4.8 qt ▶ PTO & HitchPTO Type Live independent (hydraulic clutch) Independent PTO Rear 540 rpm @ 2476 engine rpm 540 rpm Mid-PTO Availability Optional 2460 rpm Category, 3-Point Hitch SAE Category I Category I Hitch Lift Capacity 3,858 lb 2,535 lb Hitch Lift Capacity (at 24”) 2,760 lb 1,962 lb Lift Control Type Position control Position control valve ▶ Transmission & DrivetrainTransmission Type Hydrostatic Hydrostatic transmission No. of Speeds 3-Range, 6 speeds (H-DS), infinitely variable in each 3 ranges Max Travel Speed (Forward) 16.8 mph 17.0 mph Max Travel Speed (Reverse) 15.1 mph 13.0 mph Clutch Not Published Not Applicable Differential Lock & Limited Slip Options Rear differential lock, standard Differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc type, mechanically activated Multi-plate wet disk Seat Suspension & Adjustability Deluxe suspension seat with swivel (standard); Air-Ride seat (optional) Seat Type: Deluxe; Seat Suspension: Adjustable Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,433 lb 1,100 lb ▶ Dimensions & ManeuverabilityOverall Width 66.5 in 53.7 in Wheelbase 74.6 in 66.7 in Ground Clearance 14.2 in 8.9 in Min. Turn Radius without Brakes 8.9 ft (with brake applied) 7.5 ft (with brake applied) Height to Top of ROPS 97.6 in 88.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model n/a (ROPS model) Not Applicable Overall Length 129.5 in (with 3-point hitch) 116.1 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,759 lb 2,191 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural - Front 8.3-16 180/85D12 R1 Agricultural - Rear 14.9-24 320/85D16 R3 Turf - Front 27-10.50LL15 24X8.50-14 R3 Turf - Rear 41-18LLx16.1 13.6-16 R4 Industrial - Front 10-16.5 23x8.5-14, 23x8.5-12 or 25x8.5-14 R4 Industrial - Rear 17.5L-24 12.4-16, 14-17.5 or 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) LA545: 2-lever quick coupler, standard; Swift-Tach, optional Loader Model LA805 LA545 Loader Lift Height 104.7 in (at pivot pin) 87.6 in (at pivot pin) Loader Lift Capacity (Full Height) 1,715 lb (at pivot pin) 1,100 lb (at pivot pin) Loader Breakout Force 2,549 lb Not Published ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
