▶ EngineEngine Manufacturer Kubota LS Mtron Engine Model V2403-CR-E4-GL2 L3C19-T Engine Type Naturally aspirated, multi-valve, liquid-cooled diesel 3 Cylinder, Liquid-cooled, Diesel, TC, CRDI No. of Cylinders 4 3 Displacement 148.5 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 42 hp 42 hp PTO Power 32.5 hp H, HC: 35.7 hp; C: 33.6 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry paper, dual element Dry Fuel System Electronic CRS (Common Rail System) Common rail direct injection (CRDI) Alternator 40 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Tandem pump - gear type Gear pump, engine drive Implement Flow 9.4 gpm 8.2 gpm Steering Flow 4.7 gpm H: 5.5 gpm; HC: 6.8 gpm; C: 4.1 gpm Total Hydraulic Flow 14.1 gpm H: 13.7 gpm; HC: 15.0 gpm; C: 12.3 gpm Overall Hydraulic Pump Flow 14.1 gpm H: 13.7 gpm; HC: 15.0 gpm; C: 12.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard (up to 3 optional) 2 Pair (1 Detent, 1 STD) No. of Optional Remote Valves Optional, up to 3: double-acting valve or float detent valve, any position Not Published ▶ Fluid CapacityFuel Tank Capacity 13.5 gal H: 10.6 gal; HC, C: 12.4 gal Coolant Capacity 7.9 qt 2.3 gal Crankcase Capacity 8.7 qt 1.6 gal Transmission / Hydraulic System Capacity 11.4 gal 11.4 gal Front Axle Fluid Capacity 6.9 qt 2.2 gal ▶ PTO & HitchPTO Type Live independent (hydraulic clutch) Independent PTO Rear 540 rpm @ 2476 engine rpm 540 rpm Mid-PTO Availability Optional Optional (2,000 rpm) Category, 3-Point Hitch SAE Category I Category I Hitch Lift Capacity 3,858 lb 2,755 lb Hitch Lift Capacity (at 24”) 2,760 lb 2,469 lb Lift Control Type Position control Position & Draft ▶ Transmission & DrivetrainTransmission Type Hydrostatic H, HC: Hydrostatic (HST); C: Synchro shuttle No. of Speeds 3-Range, 6 speeds (H-DS), infinitely variable in each H, HC: 3 ranges (HST); C: F16 x R16 Max Travel Speed (Forward) 16.8 mph Not Published Max Travel Speed (Reverse) 15.1 mph Not Published Clutch Not Published Gear: Dry single clutch; HST: Not Applicable Differential Lock & Limited Slip Options Rear differential lock, standard Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Wet disc type, mechanically activated Wet, Multi-disc Seat Suspension & Adjustability Deluxe suspension seat with swivel (standard); Air-Ride seat (optional) Not Published Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing Mechanical front-wheel drive (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity 1,433 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 66.5 in 62.5 in Wheelbase 74.6 in 73.2 in Ground Clearance 14.2 in Not Published Min. Turn Radius without Brakes 8.9 ft (with brake applied) 10.3 ft Height to Top of ROPS 97.6 in H: 95 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model n/a (ROPS model) HC, C: 90 in Overall Length 129.5 in (with 3-point hitch) 133 in (frame to link) ▶ WeightTractor Weight (Base) 3,759 lb H: 3,935 lb; HC: 4,446 lb; C: 4,380 lb Weight with ROPS and Loader Not Published H: 4,715 lb (3,935 + 780, computed); LL4106 loader without bucket Weight with Cab and Loader Not Published HC: 5,226 lb (4,446 + 780, computed); C: 5,160 lb (4,380 + 780, computed); LL4106 loader without bucket ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial Agricultural, Turf, Industrial R1 Agricultural - Front 8.3-16 9.5-16 R1 Agricultural - Rear 14.9-24 13.6-24 R3 Turf - Front 27-10.50LL15 28x8.5-15 R3 Turf - Rear 41-18LLx16.1 41x14-20 R4 Industrial - Front 10-16.5 12-16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) LL4106, LL4001: 2-lever skid-steer coupler, fits universal skid-steer attachments Loader Model LA805 LL4106; LL4001 Loader Lift Height 104.7 in (at pivot pin) LL4106: 94.4 in; LL4001: 104.3 in Loader Lift Capacity (Full Height) 1,715 lb (at pivot pin) LL4106: 2,680 lb (at pivot pin); LL4001: 2,998 lb (at pivot pin) Loader Breakout Force 2,549 lb LL4106: 4,063 lb (at pivot pin); LL4001: 4,295 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours 6-year limited powertrain warranty ▶ ITC Company AccessoriesAccessories that fit None tagged yet
