▶ EngineEngine Manufacturer Kubota YANMAR Engine Model Not Published 4TNV88C-MLST Engine Type Direct injection, vertical, water-cooled 4-cycle diesel; natural aspiration with EGR 4-cylinder, liquid-cooled, diesel, naturally aspirated, CRDI No. of Cylinders 4 4 Displacement 148.5 in³ 133.6 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 42 hp 42.5 hp PTO Power 32.5 hp 35.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry paper, dual element Dry Fuel System Electronic CRS (Common Rail System) CRDI (common rail direct injection) Alternator 40 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Tandem pump - gear type Gear pump Implement Flow 9.4 gpm 7.4 gpm Steering Flow 4.7 gpm 5.0 gpm Total Hydraulic Flow 14.1 gpm 12.4 gpm Overall Hydraulic Pump Flow 14.1 gpm 12.4 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard (up to 3 optional) None No. of Optional Remote Valves Optional, up to 3 Remote valve 1st / 2nd (optional) ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 10.6 gal Coolant Capacity 7.9 qt Not Published Crankcase Capacity 8.7 qt Not Published Transmission / Hydraulic System Capacity 11.4 gal Not Published Front Axle Fluid Capacity 6.9 qt Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 1 speed: 540 rpm Standard (540 rpm) Mid-PTO Availability Optional Available (option) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,858 lb 1,808 lb Hitch Lift Capacity (at 24”) 2,760 lb 1,433 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST Plus) Synchro Shuttle No. of Speeds 3 ranges F12 x R12 Max Travel Speed (Forward) 16.8 mph Not Published Max Travel Speed (Reverse) 15.1 mph Not Published Clutch HST-LE (4WD, ROPS), HSTC-LE (4WD, CAB): N/A Dry Single Differential Lock & Limited Slip Options Rear differential lock, standard Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc type Wet, multi-disc Seat Suspension & Adjustability Deluxe suspension seat (standard); Air-Ride seat (optional) Not Published Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,433 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 66.5 in 66 in Wheelbase 74.6 in 74 in Ground Clearance 14.2 in Not Published Min. Turn Radius without Brakes 8.9 ft (with brake applied) 11.8 ft (3.6 m) Height to Top of ROPS 97.6 in 95 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model n/a (ROPS model) Not Published Overall Length 121.5 in (without 3-point hitch) 125 in (frame to link) ▶ WeightTractor Weight (Base) 3,748 lb 3,250 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf or Industrial tires (options) Agricultural, industrial, turf and VT; VT same size as industrial R1 Agricultural - Front 8.3-16 7-14 R1 Agricultural - Rear 14.9-24 11.2-24 R3 Turf - Front 27X10.50LL-15 25x8.50-14 R3 Turf - Rear 41X18LL-16.1 41x14.00-20 R4 Industrial - Front 10-16.5 27x8.50-15 R4 Industrial - Rear 17.5L-24 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System LA805: 2-lever quick coupler (standard); hydraulic 2-lever quick coupler (optional); single lever hose quick coupler (optional) LL3003: ISO 24410 Quick Attaching Coupler Loader Model LA805 LL3003, LL3004 Loader Lift Height 104.7 in (at pivot pin) LL3003, LL3004: 94.3 in Loader Lift Capacity (Full Height) 1,715 lb (at pivot pin) LL3003, LL3004: 2,063 lb (at pivot pin, maximum height) Loader Breakout Force 2,549 lb LL3003, LL3004: 3,723 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Two-year bumper to bumper; 6-year limited powertrain ▶ ITC Company AccessoriesAccessories that fit None tagged yet
