▶ EngineEngine Manufacturer Kubota TYM Engine Model V2403-CR-E4-LB1 T2300N2 Engine Type 4-cylinder, multi-valve, naturally aspirated, common-rail, liquid-cooled diesel 4-cylinder, naturally aspirated diesel No. of Cylinders 4 4 Displacement 148.5 in³ 139.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 47.3 hp 48 hp PTO Power F (2WD gear), DT (4WD gear): 39.3 hp; HST (4WD): 37.8 hp 38.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled, water with pressurized radiator Liquid-cooled Air Cleaner Dry paper dual element Dry element Fuel System Common-rail, direct injection, electronic control IDI Alternator 40 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Open center tandem pump, gear type Dual gear pump Implement Flow 7.8 gpm 11.4 gpm Steering Flow 4.7 gpm 5.2 gpm Total Hydraulic Flow 12.5 gpm 16.5 gpm Overall Hydraulic Pump Flow 12.5 gpm 16.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None standard (optional, up to 4) No. of Optional Remote Valves Up to 3: self-canceling detent valve or float detent valve Up to 4 ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 11.8 gal Coolant Capacity 6.9 qt 6.2 qt Crankcase Capacity 8.7 qt 4.8 qt Transmission / Hydraulic System Capacity 10.6 gal 4820R: 10.3 gal; 4820H: 11.1 gal Front Axle Fluid Capacity 6.9 qt 6.8 qt ▶ PTO & HitchPTO Type Live independent PTO with hydraulic clutch Independent PTO Rear 540 rpm 540/750 rpm Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,870 lb 3,306 lb Hitch Lift Capacity (at 24”) 2,310 lb 2,425 lb Lift Control Type Position control (draft control optional) Position control ▶ Transmission & DrivetrainTransmission Type F (2WD gear), DT (4WD gear): synchronized shuttle, 8F/8R; HST (4WD): hydrostatic, 3-range 4820R: Synchromesh; 4820H: HST No. of Speeds F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range 4820R: F16 x R16; 4820H: 4-Range Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 14.9 mph; HST (4WD): 15.8 mph 4820R: 16 mph; 4820H: 19.5 mph Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 14.3 mph; HST (4WD): 14.2 mph 4820R: 15.2 mph; 4820H: 19.5 mph Clutch F (2WD gear), DT (4WD gear): dry type, single plate; HST (4WD): no transmission clutch 4820R: Dry single type; 4820H: N/A (HST) Differential Lock & Limited Slip Options Rear differential lock standard Standard differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (factory certified) with retractable seat belt Not Published Steering Hydrostatic power steering Hydrostatic Brakes Mechanical wet disc type, pedals can be locked together Wet, multi-disc Seat Suspension & Adjustability Not Published Suspension seat Front Axle Type F (2WD gear): tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): bevel-gear front axle, non-adjustable tread spacing 4WD (selectable 2WD/4WD) Front Axle Rating F (2WD gear): 3,300 lb (at 50.4 in tread); DT (4WD gear), HST (4WD): 3,300 lb (at 45.5 in tread) Not Published Drawbar Capacity 1,430 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 62.4 in 64.9 in Wheelbase F (2WD gear): 72.8 in; DT (4WD gear), HST (4WD): 72.6 in 71.1 in Ground Clearance 15.2 in 15.5 in Min. Turn Radius without Brakes F (2WD gear): 10.2 ft; DT (4WD gear), HST (4WD): 11.5 ft L: 128.7 in; R: 126.0 in Height to Top of ROPS 91.7 in 98.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length F (2WD gear): 130.3 in; DT (4WD gear), HST (4WD): 127.4 in (with 3-point hitch) 127.4 in (with 3-point hitch) ▶ WeightTractor Weight (Base) F (2WD gear): 3,219 lb; DT (4WD gear): 3,296 lb; HST (4WD): 3,307 lb 3,831 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front F (2WD gear): 7.5L-15, 6-16; DT (4WD gear), HST (4WD): 8.3-16 9.5-16 R1 Agricultural - Rear 14.9-24 13.6-26 R3 Turf - Front 27x8.5-15 (2WD and 4WD); 27x10.5-15 (4WD) 27x8.5-15 / 29x12.5-15 R3 Turf - Rear 44x18-20 41x14-20 / 44x18-20 R4 Industrial - Front 10-16.5 (4WD) 12-16.5 R4 Industrial - Rear 17.5L-24 (4WD) 17.5Lx24 ▶ Loader & AttachmentsQuick Attach Loader System 2-lever quick coupler, tool-free attach and detach BL200: Quick attach mechanism Loader Model LA765 BL200 Loader Lift Height LA765: 105.2 in BL200: 106.6 in Loader Lift Capacity (Full Height) LA765: 1,684 lb BL200: 2,701 lb (at pivot pin) Loader Breakout Force LA765: 3,153 lbf BL200: 3,660 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months ▶ ITC Company AccessoriesAccessories that fit None tagged yet
