▶ EngineEngine Manufacturer Kubota KIOTI (Daedong) Engine Model V2403-CR-E4-GL4 4A200T Engine Type Naturally aspirated, multi-valve, liquid-cooled diesel Turbocharged diesel No. of Cylinders 4 4 Displacement 148.5 in³ 122 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 49 hp 49 hp PTO Power 41 hp 41.5 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Not Published Air Cleaner Dry paper, dual element Dual stage air filter cartridge Fuel System Electronic CRS (Common Rail System) Not Published Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Tandem pump - gear type Not Published Implement Flow 9.8 gpm 9.9 gpm Steering Flow 4.9 gpm 4.3 gpm Total Hydraulic Flow 14.7 gpm 14.2 gpm Overall Hydraulic Pump Flow 14.7 gpm 14.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard (up to 3 optional) 1 No. of Optional Remote Valves Optional, up to 3: double-acting valve or float detent valve, any position Not Published ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 11.5 gal Coolant Capacity 8.7 qt Not Published Crankcase Capacity 8.7 qt Not Published Transmission / Hydraulic System Capacity 11.4 gal Not Published Front Axle Fluid Capacity 8.9 qt Not Published ▶ PTO & HitchPTO Type Live independent (hydraulic clutch) Hydraulic independent PTO Rear 540 rpm @ 2550 engine rpm 540 rpm Mid-PTO Availability Optional Not Published Category, 3-Point Hitch SAE Category I Category I (Category II ends optional) Hitch Lift Capacity 3,858 lb Not Published Hitch Lift Capacity (at 24”) 2,756 lb 2,828 lb Lift Control Type Position control Position, Draft and Mixed control ▶ Transmission & DrivetrainTransmission Type Glide Shift Synchronized shuttle No. of Speeds 12Fx8R 12F/12R Max Travel Speed (Forward) 16.0 mph 15.84 mph Max Travel Speed (Reverse) 15.2 mph Not Published Clutch Not Published Dry single plate Differential Lock & Limited Slip Options Rear differential lock, standard Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydraulic power steering Brakes Wet disc type, mechanically activated Wet disc Seat Suspension & Adjustability Deluxe suspension seat with swivel; Air-Ride seat (optional) Adjustable seat Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing 4WD (MFWD) Front Axle Rating Not Published Not Published Drawbar Capacity 1,433 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 66.5 in 61.0 in Wheelbase 74.6 in 71.6 in Ground Clearance Not Published 14.5 in Min. Turn Radius without Brakes 8.9 ft (with brake applied) 125.2 in Height to Top of ROPS 97.6 in 88 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable 91 in Overall Length 129.5 in (with 3-point hitch) 130.7 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,836 lb 3,813 lb (with ag tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf (Option 1) or R3 LSW Turf (Option 2); R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 8.3-16 9.5-16 R1 Agricultural - Rear 14.9-24 14.9-24 R3 Turf - Front 29x12.50-15 29x12.5-15 R3 Turf - Rear 44x18-20 21.5L-16.1 R4 Industrial - Front 10-16.5 12x16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Not Published Loader Model Not Published KL1470; KL1590 Loader Lift Height Not Published KL1470: 111.44 in; KL1590: 121.06 in Loader Lift Capacity (Full Height) Not Published KL1470: 2,100 lb; KL1590: 2,500 lb Loader Breakout Force Not Published KL1470: 3,400 lb; KL1590: 4,000 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published ▶ ITC Company AccessoriesAccessories that fit
