▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403-CR-E4-GL4 V2403-CR-TE4-GL1 Engine Type Naturally aspirated, multi-valve, liquid-cooled diesel Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged No. of Cylinders 4 4 Displacement 148.5 in³ 148.5 in³ Rated Engine Speed 2700 rpm 2700 rpm Engine Power (Gross) 49 hp 52 hp PTO Power 41 hp 44 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry paper, dual element Dry paper, dual element Fuel System Electronic CRS (Common Rail System) Electronic Common Rail System (CRS) Alternator 40 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Tandem pump - gear type Tandem pump - gear type Implement Flow 9.8 gpm 9.8 gpm Steering Flow 4.9 gpm 4.9 gpm Total Hydraulic Flow 14.7 gpm 14.7 gpm Overall Hydraulic Pump Flow 14.7 gpm 14.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard (up to 3 optional) Not Published No. of Optional Remote Valves Optional, up to 3: double-acting valve or float detent valve, any position Optional, up to 3: double-acting valve or float detent valve, any position ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 13.5 gal Coolant Capacity 8.7 qt 8.7 qt Crankcase Capacity 8.7 qt 9.9 qt Transmission / Hydraulic System Capacity 11.4 gal 11.9 gal Front Axle Fluid Capacity 8.9 qt Not Published ▶ PTO & HitchPTO Type Live independent (hydraulic clutch) Live independent (hydraulic clutch) PTO Rear 540 rpm @ 2550 engine rpm 540 rpm @ 2550 engine rpm Mid-PTO Availability Optional Optional Category, 3-Point Hitch SAE Category I SAE Category I & II Hitch Lift Capacity 3,858 lb 3,858 lb Hitch Lift Capacity (at 24”) 2,756 lb 2,976 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Glide Shift Glide Shift No. of Speeds 12Fx8R 12Fx8R Max Travel Speed (Forward) 16.0 mph 16.5 mph Max Travel Speed (Reverse) 15.2 mph 15.8 mph Clutch Not Published Dry type single stage Differential Lock & Limited Slip Options Rear differential lock, standard Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc type, mechanically activated Wet disc type, mechanically activated Seat Suspension & Adjustability Deluxe suspension seat with swivel; Air-Ride seat (optional) Suspension seat with swivel function Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity 1,433 lb 1,433 lb ▶ Dimensions & ManeuverabilityOverall Width 66.5 in 67.3 in Wheelbase 74.6 in 75.4 in Ground Clearance Not Published 15.4 in Min. Turn Radius without Brakes 8.9 ft (with brake applied) 9.2 ft (with brake applied) Height to Top of ROPS 97.6 in 98.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable Not Published Overall Length 129.5 in (with 3-point hitch) 135.0 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,836 lb 3,979 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf (Option 1) or R3 LSW Turf (Option 2); R4 Industrial Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470) R1 Agricultural - Front 8.3-16 9.5-16 R1 Agricultural - Rear 14.9-24 14.9-26; 13.6-28 R3 Turf - Front 29x12.50-15 29X12.50-15 R3 Turf - Rear 44x18-20 44X18-20 R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Loader Model Not Published LA1055 Loader Lift Height Not Published 112.7 in (at pivot pin) Loader Lift Capacity (Full Height) Not Published 2,361 lb (at pivot pin) Loader Breakout Force Not Published 3,171 lbf ▶ WarrantyWarranty Length & Coverage Not Published Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
