▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403-CR-E4-GL4 F2803-ELA Engine Type Naturally aspirated, multi-valve, liquid-cooled diesel Vertical, water-cooled, 4-cycle diesel, 5-cylinder No. of Cylinders 4 5 Displacement 148.5 in³ 167.6 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 49 hp 54 hp PTO Power 41 hp 45 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry paper, dual element Dual dry elements Fuel System Electronic CRS (Common Rail System) Not Published Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Tandem pump - gear type Not Published Implement Flow 9.8 gpm Not Published Steering Flow 4.9 gpm Not Published Total Hydraulic Flow 14.7 gpm 17.1 gpm Overall Hydraulic Pump Flow 14.7 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard (up to 3 optional) 1 No. of Optional Remote Valves Optional, up to 3: double-acting valve or float detent valve, any position Not Published ▶ Fluid CapacityFuel Tank Capacity 13.5 gal ROPS: 17.2 gal; Cab: 25.1 gal Coolant Capacity 8.7 qt 7.7 qt Crankcase Capacity 8.7 qt 8.5 qt Transmission / Hydraulic System Capacity 11.4 gal Not Published Front Axle Fluid Capacity 8.9 qt Not Published ▶ PTO & HitchPTO Type Live independent (hydraulic clutch) Live PTO Rear 540 rpm @ 2550 engine rpm 540 rpm Mid-PTO Availability Optional Not Published Category, 3-Point Hitch SAE Category I Category II/I Hitch Lift Capacity 3,858 lb 4,200 lb Hitch Lift Capacity (at 24”) 2,756 lb 3,307 lb Lift Control Type Position control Position, draft and mix control ▶ Transmission & DrivetrainTransmission Type Glide Shift Synchronized shuttle, 8F/8R (12F/12R with creeper) No. of Speeds 12Fx8R 8F/8R (12F/12R with creeper) Max Travel Speed (Forward) 16.0 mph Not Published Max Travel Speed (Reverse) 15.2 mph Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Rear differential lock, standard Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc type, mechanically activated Mechanical wet disc Seat Suspension & Adjustability Deluxe suspension seat with swivel; Air-Ride seat (optional) Not Published Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,433 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 66.5 in 67.2 in (minimum) Wheelbase 74.6 in ROPS: 78.7 in; Cab: 81.7 in Ground Clearance Not Published 16.9 in Min. Turn Radius without Brakes 8.9 ft (with brake applied) Not Published Height to Top of ROPS 97.6 in 93.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable 98.1 in Overall Length 129.5 in (with 3-point hitch) 2WD ROPS: 137.6 in; 4WD ROPS: 134.1 in; 2WD cab: 140.6 in; 4WD cab: 137.1 in ▶ WeightTractor Weight (Base) 3,836 lb 2WD ROPS: 3,748 lb; 4WD ROPS: 3,968 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf (Option 1) or R3 LSW Turf (Option 2); R4 Industrial Standard: 6.5-16 front (2WD), 9.5-22 front (4WD), 14.9-28 rear R1 Agricultural - Front 8.3-16 8.3-24 R1 Agricultural - Rear 14.9-24 14.9-28 R3 Turf - Front 29x12.50-15 2WD: 9.00-10; 4WD: 29x12.5-15 R3 Turf - Rear 44x18-20 21.5L-16.1 R3 R4 Industrial - Front 10-16.5 12.5/80-18 R4 R4 Industrial - Rear 17.5L-24 16.9-24 R4 ▶ Loader & AttachmentsQuick Attach Loader System 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Not Published Loader Model Not Published LA1002 Loader Lift Height Not Published LA1002: 115.6 in Loader Lift Capacity (Full Height) Not Published LA1002: 2,579 lb (at pivot pin) Loader Breakout Force Not Published LA1002: 3,330 lbf ▶ WarrantyWarranty Length & Coverage Not Published Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
