▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403-CR-E5 V2403-CR-TE4-GL1 Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged No. of Cylinders 4 4 Displacement 148.5 in³ 148.5 in³ Rated Engine Speed 2600 rpm 2700 rpm Engine Power (Gross) 48.4 hp 52 hp PTO Power 40.5 hp 44 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry type, primary and secondary element Dry paper, dual element Fuel System Direct injection Electronic Common Rail System (CRS) Alternator 45 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Not Published Tandem pump - gear type Implement Flow 7.8 gpm 9.8 gpm Steering Flow 4.7 gpm 4.9 gpm Total Hydraulic Flow 12.5 gpm (7.8 + 4.7, computed) 14.7 gpm Overall Hydraulic Pump Flow 12.5 gpm (7.8 + 4.7, computed) 14.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Optional: double-acting valve, or double-acting valve with float position (float valve as second segment only) Optional, up to 3: double-acting valve or float detent valve, any position ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 13.5 gal Coolant Capacity 6.9 qt 8.7 qt Crankcase Capacity 8.7 qt 9.9 qt Transmission / Hydraulic System Capacity 10.6 gal 11.9 gal Front Axle Fluid Capacity 6.9 qt Not Published ▶ PTO & HitchPTO Type Live independent PTO with hydraulic clutch Live independent (hydraulic clutch) PTO Rear 540 rpm 540 rpm @ 2550 engine rpm Mid-PTO Availability Not Published Optional Category, 3-Point Hitch SAE Category I SAE Category I & II Hitch Lift Capacity 2,870 lb 3,858 lb Hitch Lift Capacity (at 24”) 2,320 lb 2,976 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Constant mesh with synchronized shuttle Glide Shift No. of Speeds 8 forward, 8 reverse 12Fx8R Max Travel Speed (Forward) 12.9 mph 16.5 mph Max Travel Speed (Reverse) 12.4 mph 15.8 mph Clutch Dry type single stage Dry type single stage Differential Lock & Limited Slip Options Rear differential lock, pedal operated Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanical, wet disc type Wet disc type, mechanically activated Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Suspension seat with swivel function Front Axle Type Cast-iron front axle 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity 1,430 lb 1,433 lb ▶ Dimensions & ManeuverabilityOverall Width 52.7 in 67.3 in Wheelbase 72.6 in 75.4 in Ground Clearance 11.5 in 15.4 in Min. Turn Radius without Brakes 8.9 ft (with brake applied) 9.2 ft (with brake applied) Height to Top of ROPS 94.9 in (61.2 in with ROPS folded) 98.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 117.7 in (without 3-point hitch) 135.0 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,362 lb 3,979 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470) R1 Agricultural - Front 7.2-16 9.5-16 R1 Agricultural - Rear 11.2-24 14.9-26; 13.6-28 R3 Turf - Front Not Published 29X12.50-15 R3 Turf - Rear Not Published 44X18-20 R4 Industrial - Front Not Published 10-16.5 R4 Industrial - Rear Not Published 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Loader Model Not Published LA1055 Loader Lift Height Not Published 112.7 in (at pivot pin) Loader Lift Capacity (Full Height) Not Published 2,361 lb (at pivot pin) Loader Breakout Force Not Published 3,171 lbf ▶ WarrantyWarranty Length & Coverage Basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: powertrain 36 months or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
