▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403-CR-E5 Not Published Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel 4-cylinder, indirect injection, liquid-cooled diesel No. of Cylinders 4 4 Displacement 148.5 in³ 148.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 48.4 hp 48 hp PTO Power 40.5 hp 37.5 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry type, primary and secondary element Not Published Fuel System Direct injection Not Published Alternator 45 A, 12 V Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 7.8 gpm Not Published Steering Flow 4.7 gpm Not Published Total Hydraulic Flow 12.5 gpm (7.8 + 4.7, computed) 25.9 gpm Overall Hydraulic Pump Flow 12.5 gpm (7.8 + 4.7, computed) 25.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Optional: double-acting valve, or double-acting valve with float position (float valve as second segment only) Not Published ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 13.2 gal Coolant Capacity 6.9 qt Not Published Crankcase Capacity 8.7 qt Not Published Transmission / Hydraulic System Capacity 10.6 gal Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Live independent PTO with hydraulic clutch Live-continuous running PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch SAE Category I Category I (standard) Hitch Lift Capacity 2,870 lb Not Published Hitch Lift Capacity (at 24”) 2,320 lb 3,310 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Constant mesh with synchronized shuttle "Feather Step" hydrostatic transmission, 3-range No. of Speeds 8 forward, 8 reverse 3-range (infinite) Max Travel Speed (Forward) 14.9 mph 15.3 mph Max Travel Speed (Reverse) 14.3 mph Not Published Clutch Dry type single stage Dry, single Differential Lock & Limited Slip Options Rear differential lock, pedal operated Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Four-post ROPS/FOPS standard Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanical, wet disc type Wet disc Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Movable seat, spins in place; tilt steering standard Front Axle Type Cast-iron front axle Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,430 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 62.2 in 74.5 in Wheelbase 72.6 in 74.0 in Ground Clearance 15.2 in Not Published Min. Turn Radius without Brakes 8.9 ft (with brake applied) 10.5 ft Height to Top of ROPS 91.7 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 122.8 in (without 3-point hitch) Not Published ▶ WeightTractor Weight (Base) 3,296 lb Not Published Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural; Turf Industrial (R4): 10-16.5 R4 front, 17.5L-24 R4 rear R1 Agricultural - Front 7.5L-15 Not Published R1 Agricultural - Rear 14.9-24 Not Published R3 Turf - Front 27X8.50-15 Not Published R3 Turf - Rear 44X18-20 Not Published R4 Industrial - Front Not Published 10-16.5 R4 R4 Industrial - Rear Not Published 17.5L-24 R4 ▶ Loader & AttachmentsQuick Attach Loader System LA766 2-Lever Quick Coupler Not Published Loader Model LA766 TL1150 Loader Lift Height 105.2 in (at pivot pin) TL1150: 116.1 in (at pivot pin) Loader Lift Capacity (Full Height) 1,676 lb (at pivot pin, max. height) TL1150: 3,000 lb (at pivot pin) Loader Breakout Force Not Published TL1150: 4,375 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: powertrain 36 months or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
