▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403-CR-TE4-GL3 V2403-CR-TE4 Engine Type Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged 4-cylinder, turbocharged, common-rail, liquid-cooled diesel No. of Cylinders 4 4 Displacement 148.5 in³ 148.6 in³ Rated Engine Speed 2600 rpm 2700 rpm Engine Power (Gross) 56 hp 54.7 hp PTO Power 46.5 hp F (2WD gear), DT (4WD gear): 45.7 hp; HST (4WD): 44.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry paper, dual element Dry, dual element Fuel System Electronic Common Rail System (CRS) Common rail direct injection Alternator 60 A, 12 V 45 A ▶ HydraulicsPump Type Tandem pump - gear type Not Published Implement Flow 9.4 gpm 9.5 gpm Steering Flow 4.7 gpm 4.9 gpm Total Hydraulic Flow 14.1 gpm 14.4 gpm (9.5 + 4.9, computed) Overall Hydraulic Pump Flow 14.1 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Optional, up to 3: double-acting valve or float detent valve, any position Up to 3 (optional) ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 13.5 gal Coolant Capacity 8.7 qt 6.9 qt Crankcase Capacity 9.9 qt 9.9 qt Transmission / Hydraulic System Capacity 11.9 gal 11.6 gal Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Live independent (hydraulic clutch) Live independent hydraulic PTO with PTO brake, wet clutch PTO Rear 540 rpm @ 2400 engine rpm 540 rpm Mid-PTO Availability Optional Not Published Category, 3-Point Hitch SAE Category I & II Category I and II Hitch Lift Capacity 3,858 lb Not Published Hitch Lift Capacity (at 24”) 2,976 lb 2,310 lb Lift Control Type Position control Position control standard, draft control optional ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission F (2WD gear), DT (4WD gear): gear-drive with synchronized shuttle, 8F/8R (4-speed main, partially synchronized 3rd and 4th); HST (4WD): hydrostatic transmission, 3-range No. of Speeds 3-range, 6 speeds (H-DS), infinitely variable in each F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range Max Travel Speed (Forward) 16.8 mph F (2WD gear), DT (4WD gear): 16.0 mph; HST (4WD): 16.1 mph Max Travel Speed (Reverse) 15.2 mph F (2WD gear), DT (4WD gear): 14.7 mph; HST (4WD): 14.5 mph Clutch Not Published F (2WD gear), DT (4WD gear): dry single plate; HST (4WD): no clutch Differential Lock & Limited Slip Options Rear differential lock, standard Rear differential lock standard (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc type, mechanically activated Mechanical wet disc Seat Suspension & Adjustability Suspension seat with swivel function High-back suspension seat Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing 4WD: Bevel gear type Front Axle Rating Not Published Not Published Drawbar Capacity 1,433 lb 1,650 lb ▶ Dimensions & ManeuverabilityOverall Width 67.3 in 69.7 in Wheelbase 75.4 in 74.6 in Ground Clearance 15.4 in 15.2 in Min. Turn Radius without Brakes 9.2 ft (with brake applied) F (2WD gear): 8.5 ft; DT (4WD gear), HST (4WD): 8.9 ft (with brake applied) Height to Top of ROPS Not Applicable 95.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.5 in Not Published Overall Length 135.0 in (with 3-point hitch) F (2WD gear): 127.8 in; DT (4WD gear), HST (4WD): 125.2 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 4,365 lb F (2WD gear): 3,474 lb; DT (4WD gear): 3,716 lb; HST (4WD): 3,734 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470) Standard ag: 7.5L-15 (2WD) or 9.5-16 (4WD) front, 14.9-26 rear R1 Agricultural - Front 9.5-16 F (2WD gear): 7.5L-15; DT (4WD gear), HST (4WD): 9.5-16 R1 Agricultural - Rear 14.9-26; 13.6-28 14.9-26 R3 Turf - Front 29X12.50-15 Not Published R3 Turf - Rear 44X18-20 Not Published R4 Industrial - Front 10-16.5 Not Published R4 Industrial - Rear 17.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) LA1065: 2-lever quick coupler standard Loader Model LA1055 LA1065 Loader Lift Height 112.7 in (at pivot pin) LA1065: 111.2 in (at pivot pin) Loader Lift Capacity (Full Height) 2,361 lb (at pivot pin) LA1065: 2,275 lb (at pivot pin) Loader Breakout Force 3,171 lbf Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
