▶ EngineEngine Manufacturer Kubota Yanmar Engine Model V2403-CR-E4-GL5 4TNV86CHT-MJT Engine Type Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged Turbocharged 4-cylinder Diesel No. of Cylinders 4 4 Displacement 148.5 in³ 127.6 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 62 hp 65 hp PTO Power 53 hp 57 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry paper, dual element Dual element (dry type with safety element) Fuel System Electronic Common Rail System (CRS) High-pressure common rail direct injection Alternator 45 A, 12 V 75 A, 12 V ▶ HydraulicsPump Type Tandem pump - gear type Dual Independent Implement Flow 9.4 gpm 10.2 gpm Steering Flow 4.7 gpm 5.7 gpm Total Hydraulic Flow 14.1 gpm 15.9 gpm Overall Hydraulic Pump Flow 14.1 gpm 15.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Optional, up to 3: double-acting valve or float detent valve, any position 3/4/5 optional ▶ Fluid CapacityFuel Tank Capacity 13.5 gal OOS: 15 gal; Cab: 14.7 gal Coolant Capacity 8.7 qt OOS: 6.8 qt; Cab: 8.0 qt Crankcase Capacity 9.9 qt 5.7 qt Transmission / Hydraulic System Capacity 11.9 gal 12.5 gal Front Axle Fluid Capacity Not Published 5.8 qt ▶ PTO & HitchPTO Type Live independent (hydraulic clutch) Independent 540 PTO Rear 540 rpm @ 2400 engine rpm 540 rpm Mid-PTO Availability Optional No mid-PTO offered Category, 3-Point Hitch SAE Category I & II Category I Hitch Lift Capacity 3,858 lb 3,130 lb Hitch Lift Capacity (at 24”) 2,976 lb 2,500 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission Standard: eHydro (3F/3R hydrostatic); Optional: 12F/12R PowrReverser No. of Speeds 3-range, 6 speeds (H-DS), infinitely variable in each Infinitely-variable, 3 range Max Travel Speed (Forward) 16.8 mph 18.6 mph Max Travel Speed (Reverse) 15.2 mph 18.6 mph Clutch Not Published n/a Differential Lock & Limited Slip Options Rear differential lock, standard Rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published ROPS - Foldable Steering Hydrostatic power steering Power steering Brakes Wet disc type, mechanically activated Wet disc Seat Suspension & Adjustability Suspension seat with swivel function Deluxe adjustable vinyl seat with arm rests, swivel and retractable seat belt; Air Seat Suspension Kit optional (open station) Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing Mechanical front wheel drive (MFWD) - Standard Front Axle Rating Not Published (Continuous) 3,307 lb Drawbar Capacity 1,433 lb Max vertical load 1,103 lb ▶ Dimensions & ManeuverabilityOverall Width 67.3 in 78.2 in Wheelbase 75.4 in 73 in Ground Clearance 15.4 in Front axle: 15.6 in Min. Turn Radius without Brakes 9.2 ft (with brake applied) 9.84 ft (3.0 m) Height to Top of ROPS 98.0 in 100.2 in Height to Top of ROPS (folded) Not Published 80.5 in Height to Top of Cab Model Not Applicable 97.4 in Overall Length 135.0 in (with 3-point hitch) 130.6 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,990 lb 3,770 lb (operating weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470) R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-16 8-16 (6PR) R1 Agricultural - Rear 14.9-26; 13.6-28 13.6-28 R3 Turf - Front 29X12.50-15 27X10.50-15 R3 Turf - Rear 44X18-20 44X18.00-20 (4PR) R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 17.5L-24 16.9-24 (6PR, R4 Industrial) ▶ Loader & AttachmentsQuick Attach Loader System 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) 440R: Quik-Park loader; 400E: non Quik-Park loader Loader Model LA1055 440R or 440R MSL; 400E on open-station tractors Loader Lift Height 112.7 in (at pivot pin) 440R: 110 in; 400E: 112 in (to pivot pin) Loader Lift Capacity (Full Height) 2,361 lb (at pivot pin) 440R NSL: 2,539 lb; 440R MSL: 2,213 lb; 400E: 2,391 lb (at pivot, full height) Loader Breakout Force 3,171 lbf 400E: 3,853 lbf at pivot point; 2,902 lbf 500 mm forward of pivot point; 440R NSL: 4,027 lbf at pivot point; 3,037 lbf 500 mm forward of pivot pin; 440R MSL: 3,844 lbf at pivot point; 3,346 lbf 500 mm forward of pivot pin ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
