▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403-CR-TIE5 V2403-CR-E4-GL5 Engine Type Direct injection, water-cooled, 4-cycle diesel, common rail system, turbocharged and intercooled Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged No. of Cylinders 4 4 Displacement 148.5 in³ 148.5 in³ Rated Engine Speed 2300 rpm 2600 rpm Engine Power (Gross) 60 hp 62 hp PTO Power 53 hp 53 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Not Published Dry paper, dual element Fuel System Common rail direct injection Electronic Common Rail System (CRS) Alternator Not Published 45 A, 12 V ▶ HydraulicsPump Type Not Published Tandem pump - gear type Implement Flow 9.83 gpm 9.4 gpm Steering Flow Not Published 4.7 gpm Total Hydraulic Flow Not Published 14.1 gpm Overall Hydraulic Pump Flow Not Published 14.1 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3 (optional) Optional, up to 3 (double-acting valve or float detent valve options, any position) ▶ Fluid CapacityFuel Tank Capacity Not Published 13.5 gal Coolant Capacity Not Published 8.7 qt Crankcase Capacity Not Published 9.9 qt Transmission / Hydraulic System Capacity Not Published 11.9 gal Front Axle Fluid Capacity Not Published 8.9 qt ▶ PTO & HitchPTO Type Independent Live independent (hydraulic clutch) PTO Rear 540 rpm 540 rpm @ 2400 engine rpm Mid-PTO Availability Not Published Optional Category, 3-Point Hitch Category I and II SAE Category I & II Hitch Lift Capacity 3858 lb 3,858 lb Hitch Lift Capacity (at 24”) 2976 lb 2,976 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission, 3-range, with Hydro-Dual Speed (H-DS) Hydrostatic transmission No. of Speeds 3-range 3-range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) 18.5 mph 16.8 mph Max Travel Speed (Reverse) Not Published 15.2 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Two-post folding ROPS; cab optional Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc type Wet disc type, mechanically activated Seat Suspension & Adjustability Not Published Suspension seat with fore/aft travel adjustment, suspension adjust knob, backrest tilt adjustment, swivel and arm rest Front Axle Type Not Published 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,433 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 133.9 in (w/o 3P) (without 3-point hitch) 135.0 in Overall Width 67.3 in 67.3 in Wheelbase 81.3 in 75.4 in Ground Clearance 15.4 in 15.4 in Min. Turn Radius without Brakes 9.5 ft (w/brake) (with brake applied) 9.2 ft (with brake applied) Height to Top of ROPS 98.0 in 98.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 93.3 in Not Applicable ▶ WeightTractor Weight (Base) 4387 lb (ROPS); 4762 lb (cab) 3,990 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 9.5-16 front, 14.9-26 rear Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470) R1 Agricultural - Front 9.5-16 9.5-16 R1 Agricultural - Rear 14.9-26 14.9-26; 13.6-28 R3 Turf - Front Not Published 29X12.50-15 R3 Turf - Rear Not Published 44X18-20 R4 Industrial - Front Not Published 10-16.5 R4 Industrial - Rear Not Published 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System LA1056, LM1056: toolless loader removal with integrated parking stands; optional third-function valve Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) Loader Model LA1056; LM1056 LA1055 Loader Lift Height LA1056: 117 in; LM1056: 117 in 112.7 in Loader Lift Capacity (Full Height) LA1056: 2427 lb; LM1056: 2471 lb 2361 lb Loader Breakout Force LA1056: 4069 lbf; LM1056: 4061 lbf 3171 lbf (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
