Kubota LX2610 vs Kubota BX23S | Side-by-side comparison | ITC Resource Center
ITC Resource Center
Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
—
KubotaLX2610
—
KubotaBX23S
Comparison loaded for 2 tractors.
Spec
KubotaLX2610
KubotaBX23S
PTO Power
19.5 hp
17.7 hp
Alternator
Not Published
40 A, 12 V
Air Cleaner
4.5 inch Dual paper element
Sheet net and replaceable treated paper element, spin on oil filter
Engine Type
E-TVCS, liquid cooled, 3-cylinder, diesel
Liquid cooled, 4-cycle, diesel
Fuel System
Not Published
Direct injection
Displacement
77 in³
54.8 in³
No. of Cylinders
3
3
Rated Engine Speed
2500 rpm
3200 rpm
Cooling System Type
Pressurized radiator
Water with pressurized radiator, reverse air-flow design
Engine Manufacturer
Kubota
Kubota
Engine Emissions Constraints
Not Published
Not Published
Engine Power (Gross)
24.8 hp
21.6 hp
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Applicable
Not Applicable
Weight with ROPS and Loader
Not Published
Not Published
Pump Type
Dual pump
Open center tandem pump gear type
Steering Flow
Not Published
1.0 gpm
Implement Flow
Not Published
5.2 gpm
Total Hydraulic Flow
8.7 gpm
6.2 gpm
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
8.7 gpm
6.2 gpm
No. of Optional Remote Valves
Not Published
2 (optional; ISO 7241-1 series A or B)
No. of Standard Remote Valves
Not Published
Not Published
R3 Turf - Rear
Not Published
26X12-12
R3 Turf - Front
Not Published
18X8.5-10
Tire Size & Options
R1 Agricultural, R4 Industrial
R3 Turf, R4 Industrial
R4 Industrial - Rear
12.4-16 / 15-19.5
26X12-12
R4 Industrial - Front
23X8.50-14 / 25X8.50-14
18X8.5-10
R1 Agricultural - Rear
12.4-16
Not Applicable
R1 Agricultural - Front
7.0-12
Not Applicable
PTO Rear
540 rpm
STD (540 rpm)
PTO Type
Independent
Live independent PTO (with hydraulic clutch)
Lift Control Type
Position control valve
Not Published
Hitch Lift Capacity
2139 lb
Not Published
Mid-PTO Availability
2500 rpm
STD (2500 rpm)
Category, 3-Point Hitch
Category I
SAE Category I Optional
Hitch Lift Capacity (at 24”)
1676 lb
680 lb
Coolant Capacity
4.5 qt
Not Published
Crankcase Capacity
4.2 qt
Not Published
Fuel Tank Capacity
7.1 gal
6.6 gal
Front Axle Fluid Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
4.0 gal
Not Published
Loader Lift Height
84 in
71.0 in
Loader Breakout Force
2245 lb
1,286 lbf (bucket pivot pin)
Price for Backhoe Option
BH77: $9,803 MSRP
Already included in base model
Price for Mid-Mount Mower
RCK60-30BB: $3,803 MSRP; RCK72-30BB: $4,556 MSRP
Not Published
Quick Attach Loader System
Front Loader (LA535 - 2 Lever Quick Coupler (STD); Swift-tach (OPT))
Swift-Tach Loader (LA340S - Two Lever Quick Attach Bucket)
Loader Lift Capacity (Full Height)
1067 lb
613 lb
Clutch
N/A
Dry type single plate - Main clutch 9.45 in.
No. of Speeds
3 ranges
2 Range (Low-High)
Transmission Type
Hydrostatic transmission
Hydrostatic transmission
Max Travel Speed (Forward)
11.2 mph
8.4 mph
Max Travel Speed (Reverse)
8.4 mph
6.5 mph
Differential Lock & Limited Slip Options
Differential lock standard
Rear differential lock standard
Brakes
Multi-plate wet disc
Mechanical, wet disc type
Steering
Hydraulic power steering
Integral power steering
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
4WD: Bevel gear front axle, non-adjustable tread spacing
$27,603 MSRP as low as (BX23S model offering includes front loader)
Warranty Length & Coverage
Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours.
