▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1305-E4-D26-Q D1105 Engine Type E-TVCS, liquid cooled, 3-cylinder, diesel E-TVCS, liquid cooled, 3-cylinder diesel No. of Cylinders 3 3 Displacement 77 in³ 68.5 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 24.8 hp 21.9 hp PTO Power 19.5 hp 19.2 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Pressurized radiator Liquid Cooled Air Cleaner 4.5 in Dual paper element Dual paper element Fuel System Indirect injection Not Published Alternator 60 A, 12 V 40 A ▶ HydraulicsPump Type Dual pump Dual pump Implement Flow 5.0 gpm 4.4 gpm Steering Flow 3.7 gpm 2.6 gpm Total Hydraulic Flow 8.7 gpm 7.0 gpm Overall Hydraulic Pump Flow 8.7 gpm 7.0 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 0 No. of Optional Remote Valves Optional, up to 2 1 ▶ Fluid CapacityFuel Tank Capacity 8.4 gal 6.1 gal Coolant Capacity 4.5 qt 4.0 qt Crankcase Capacity 4.2 qt 3.3 qt Transmission / Hydraulic System Capacity 4.0 gal 3.3 gal Front Axle Fluid Capacity 5.0 qt 0.9 gal ▶ PTO & HitchPTO Type Independent Transmission driven with one way clutch PTO Rear 540 rpm 540, 1000 rpm Mid-PTO Availability 2500 rpm 2500 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2139 lb 1653 lb Hitch Lift Capacity (at 24”) 1676 lb 1290 lb Lift Control Type Position control valve Position control valve ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission Gear (9 Forward, 3 Reverse) No. of Speeds 3 ranges 9 Forward, 3 Reverse Max Travel Speed (Forward) 11.2 mph 11.7 mph Max Travel Speed (Reverse) 8.4 mph 6.0 mph Clutch Not Published Dry single plate Differential Lock & Limited Slip Options Differential lock standard Standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydraulic power steering Integral type power steering Brakes Multi-plate wet disc Multi-plate wet disc Seat Suspension & Adjustability Deluxe high-back suspension seat Fore and aft slide adjustment (position adjust lever) Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1100 lb 660 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 103.9 in (without 3-point hitch) 93.9 in (without 3-point hitch) Overall Width 53.7 in 44.3 in Wheelbase 65.6 in 61.4 in Ground Clearance 14.6 in 12.0 in Min. Turn Radius without Brakes 6.9 ft (with brake applied) 6.9 ft (with brake applied) Height to Top of ROPS Not Published 83.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 84.6 in Not Published ▶ WeightTractor Weight (Base) 2293 lb 1521 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial, R14 Farm (R1): 6-12 front, 9.5-16 rear; Turf (R3): 23x8.50-12 front, 33x12.5-15 rear; Industrial (R4): 23x8.50-12 front, 12-16.5 rear; R14: 23x8.50-12 front, 12-16.5 rear R1 Agricultural - Front 7.0-12 6-12 R1 Agricultural - Rear 12.4-16 9.5-16 R3 Turf - Front 24x8.50-14 23x8.50-12 R3 Turf - Rear 13.6-16 33x12.5-15 R4 Industrial - Front 23X8.50-14 23x8.50-12 R4 Industrial - Rear 12.4-16 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA535 - 2 Lever Quick Coupler (STD); Swift-tach (OPT)) LA435 Swift-Tach Loader; 1-lever Quick Coupler (standard); 2-Lever Quick Coupler (optional) Loader Model LA535 LA435 Loader Lift Height 84 in 78.5 in Loader Lift Capacity (Full Height) 1067 lb 948 lb Loader Breakout Force 2245 lb 2,146 lbf ▶ WarrantyWarranty Length & Coverage Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit
