▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1305-E4-D36-R D1105-D10 Engine Type 3-cylinder, indirect injection, liquid-cooled diesel Diesel, 3-cylinder, liquid-cooled, indirect injection No. of Cylinders 3 3 Displacement 77 in³ 68.5 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 24.8 hp 24 hp PTO Power 19.5 hp 18 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Pressurized radiator Liquid-cooled Air Cleaner 4.5 in Dual paper element Not Published Fuel System Indirect injection Indirect injection Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Dual pump Not Published Implement Flow 5.0 gpm 5.8 gpm Steering Flow 3.7 gpm Not Published Total Hydraulic Flow 8.7 gpm Not Published Overall Hydraulic Pump Flow 8.7 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None (remote valves optional) Not Published No. of Optional Remote Valves Optional, up to 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 7.1 gal 6.3 gal Coolant Capacity 4.5 qt 3.6 qt Crankcase Capacity 4.2 qt 3.6 qt Transmission / Hydraulic System Capacity 4.0 gal 3.2 gal Front Axle Fluid Capacity 5.0 qt Not Published ▶ PTO & HitchPTO Type Independent Live PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Mid-PTO, 2537 rpm (Kubota 10-tooth) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,139 lb 1,280 lb Hitch Lift Capacity (at 24”) 1,676 lb 1,015 lb Lift Control Type Position control valve Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission Hydrostatic transmission, 2-range No. of Speeds 3 ranges 2-range Max Travel Speed (Forward) 11.2 mph Not Published Max Travel Speed (Reverse) 8.4 mph Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Differential lock standard Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post ROPS Steering Hydraulic power steering Power steering Brakes Multi-plate wet disc Wet disc Seat Suspension & Adjustability Standard seat Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,100 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 101.8 in (without 3-point hitch) 91.7 in Overall Width 53.7 in 46.3 in Wheelbase 65.6 in 59.4 in Ground Clearance 14.6 in 12.8 in Min. Turn Radius without Brakes 6.9 ft (with brake applied) Not Published Height to Top of ROPS 88.4 in 77.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1,830 lb 1,570 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial, R14 Ag: 6.50-10 (2WD) or 7.00-12 (4WD) front, 11.2-16 rear R1 Agricultural - Front 7-12 2WD: 6.50-10; 4WD: 7.00-12 R1 Agricultural - Rear 12.4-16 11.2-16 R3 Turf - Front 24x8.50-14 Not Published R3 Turf - Rear 13.6-16 Not Published R4 Industrial - Front 23X8.50-14 / 25X8.50-14 Not Published R4 Industrial - Rear 12.4-16 / 15-19.5 Not Published ▶ Loader & AttachmentsQuick Attach Loader System LA535: 2-lever quick coupler, standard; Swift-Tach, optional Not Published Loader Model LA535 LA301; LA351 Loader Lift Height 84 in LA301: 70.5 in; LA351: 70.5 in Loader Lift Capacity (Full Height) 1,067 lb LA301: 660 lb; LA351: 770 lb Loader Breakout Force 2,245 lb LA301: 1,150 lbf; LA351: 1,335 lbf ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
