▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1305-E4-D36-R D1105-E4-TLB-1 Engine Type 3-cylinder, indirect injection, liquid-cooled diesel 3-cylinder, indirect injection, liquid-cooled diesel No. of Cylinders 3 3 Displacement 77 in³ 68.5 in³ Rated Engine Speed 2500 rpm 2800 rpm Engine Power (Gross) 24.8 hp 26 hp PTO Power 19.5 hp 19.5 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Pressurized radiator Liquid-cooled Air Cleaner 4.5 in Dual paper element Single element Fuel System Indirect injection Indirect injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Dual pump Not Published Implement Flow 5.0 gpm 7.0 gpm Steering Flow 3.7 gpm 4.2 gpm Total Hydraulic Flow 8.7 gpm 11.1 gpm Overall Hydraulic Pump Flow 8.7 gpm 11.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None (remote valves optional) Not Published No. of Optional Remote Valves Optional, up to 2 Up to 3 ▶ Fluid CapacityFuel Tank Capacity 7.1 gal 8.1 gal Coolant Capacity 4.5 qt 4.7 qt Crankcase Capacity 4.2 qt 3.2 qt Transmission / Hydraulic System Capacity 4.0 gal 6.9 gal Front Axle Fluid Capacity 5.0 qt 5.0 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category I (optional) Hitch Lift Capacity 2,139 lb 2,139 lb Hitch Lift Capacity (at 24”) 1,676 lb 1,676 lb Lift Control Type Position control valve Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission HST Plus hydrostatic transmission, 3-range No. of Speeds 3 ranges 3-range (infinite) Max Travel Speed (Forward) 11.2 mph 11.1 mph Max Travel Speed (Reverse) 8.4 mph 9.8 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Differential lock standard Rear axle differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Four-post ROPS/FOPS standard Steering Hydraulic power steering Hydrostatic power steering Brakes Multi-plate wet disc Wet disc Seat Suspension & Adjustability Standard seat Reversible seat; tilt steering standard Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,100 lb 1,100 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 101.8 in (without 3-point hitch) 100.7 in (without 3-point hitch) Overall Width 53.7 in 53.7 in Wheelbase 65.6 in 62.2 in Ground Clearance 14.6 in 13.8 in Min. Turn Radius without Brakes 6.9 ft (with brake applied) 8.2 ft Height to Top of ROPS 88.4 in 89.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1,830 lb 2,606 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial, R14 Industrial (R4): 23x8.5-14 R4 front, 12.4-16 R4 rear; turf 24x8.50-14 front, 13.6-16 rear R1 Agricultural - Front 7-12 Not Published R1 Agricultural - Rear 12.4-16 Not Published R3 Turf - Front 24x8.50-14 24x8.50-14 R3 Turf - Rear 13.6-16 13.6-16 R4 Industrial - Front 23X8.50-14 / 25X8.50-14 23x8.50-14 R4 R4 Industrial - Rear 12.4-16 / 15-19.5 12.4-16 R4 ▶ Loader & AttachmentsQuick Attach Loader System LA535: 2-lever quick coupler, standard; Swift-Tach, optional TL500: 2-lever quick coupler standard Loader Model LA535 TL500 Loader Lift Height 84 in TL500: 94.5 in Loader Lift Capacity (Full Height) 1,067 lb TL500: 1,301 lb Loader Breakout Force 2,245 lb TL500: 2,343 lbf ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
