▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1305-E4-D36-R D1305-E4-D26-R Engine Type 3-cylinder, indirect injection, liquid-cooled diesel 3-cylinder, indirect injection, liquid-cooled diesel No. of Cylinders 3 3 Displacement 77 in³ 77.0 in³ Rated Engine Speed 2500 rpm 2500 rpm Engine Power (Gross) 24.8 hp 24.8 hp PTO Power 19.5 hp 19.5 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Pressurized radiator Liquid-cooled, pressurized radiator Air Cleaner 4.5 in Dual paper element 4.0 in dual paper element Fuel System Indirect injection Indirect injection Alternator 40 A, 12 V B2650HSD (ROPS): 14.5 A; B2650HSDC (cab): 40 A, 12 V ▶ HydraulicsPump Type Dual pump Dual pump Implement Flow 5.0 gpm 5.3 gpm Steering Flow 3.7 gpm 3.7 gpm Total Hydraulic Flow 8.7 gpm 8.7 gpm Overall Hydraulic Pump Flow 8.7 gpm 8.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None (remote valves optional) 1 (rear outlet) No. of Optional Remote Valves Optional, up to 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 7.1 gal 7.3 gal Coolant Capacity 4.5 qt 4.5 qt Crankcase Capacity 4.2 qt 4.2 qt Transmission / Hydraulic System Capacity 4.0 gal 4.0 gal Front Axle Fluid Capacity 5.0 qt Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Standard mid-PTO, 2500 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,139 lb 2,139 lb Hitch Lift Capacity (at 24”) 1,676 lb 1,676 lb Lift Control Type Position control valve Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission Hydrostatic transmission, 3-range No. of Speeds 3 ranges 3-range Max Travel Speed (Forward) 11.2 mph 11.9 mph Max Travel Speed (Reverse) 8.4 mph 9.5 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Differential lock standard Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (cab optional) Steering Hydraulic power steering Hydraulic power steering Brakes Multi-plate wet disc Multi-plate wet disc Seat Suspension & Adjustability Standard seat Deluxe seat with parallel link and damper seat suspension Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,100 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 101.8 in (without 3-point hitch) 101.2 in (without 3-point hitch) Overall Width 53.7 in 53.7 in Wheelbase 65.6 in 65.6 in Ground Clearance 14.6 in 14.6 in Min. Turn Radius without Brakes 6.9 ft (with brake applied) 6.9 ft (with brake applied) Height to Top of ROPS 88.4 in 88.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 84.6 in ▶ WeightTractor Weight (Base) 1,830 lb 1,786 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial, R14 Standard farm (R1): 7-12 front, 12.4-16 rear; turf and industrial optional R1 Agricultural - Front 7-12 7-12 R1 Agricultural - Rear 12.4-16 12.4-16 R3 Turf - Front 24x8.50-14 24x8.50-14 R3 Turf - Rear 13.6-16 13.6-16 R4 Industrial - Front 23X8.50-14 / 25X8.50-14 23x8.50-14 R4 Industrial - Rear 12.4-16 / 15-19.5 12.4-16 ▶ Loader & AttachmentsQuick Attach Loader System LA535: 2-lever quick coupler, standard; Swift-Tach, optional LA534A: 2-lever quick coupler (optional), quick attach/detach mounting Loader Model LA535 LA534A Loader Lift Height 84 in LA534A: 84.6 in Loader Lift Capacity (Full Height) 1,067 lb LA534A: 1,146 lb Loader Breakout Force 2,245 lb LA534A: 2,321 lbf ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
