▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1305-E4-D36-R D1703-M-DI-E4 / D1703-M-DI-E4K Engine Type 3-cylinder, indirect injection, liquid-cooled diesel Direct injection, vertical, water-cooled 4-cycle, diesel No. of Cylinders 3 3 Displacement 77 in³ 100.5 in³ Rated Engine Speed 2500 rpm 2200 rpm Engine Power (Gross) 24.8 hp 23.3 hp PTO Power 19.5 hp 18.4 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Pressurized radiator Water-cooled Air Cleaner 4.5 in Dual paper element Dry type, single element Fuel System Indirect injection Direct injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Dual pump Not Published Implement Flow 5.0 gpm 5.2 gpm Steering Flow 3.7 gpm 3.1 gpm Total Hydraulic Flow 8.7 gpm 8.28 gpm (5.15 + 3.13, computed) Overall Hydraulic Pump Flow 8.7 gpm 8.28 gpm (5.15 + 3.13, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None (remote valves optional) Not Published No. of Optional Remote Valves Optional, up to 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 7.1 gal 11.1 gal Coolant Capacity 4.5 qt 6.3 qt Crankcase Capacity 4.2 qt 6.0 qt Transmission / Hydraulic System Capacity 4.0 gal HST (4WD): 6.9 gal; DT (2WD): 7.4 gal; DT (4WD): 7.5 gal Front Axle Fluid Capacity 5.0 qt 4.8 qt ▶ PTO & HitchPTO Type Independent DT (2WD), DT (4WD): transmission-driven with overrunning clutch; HST (4WD): live-independent, hydraulic PTO with brake, wet PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I SAE Category I Hitch Lift Capacity 2,139 lb 1,874 lb Hitch Lift Capacity (at 24”) 1,676 lb 1,389 lb Lift Control Type Position control valve Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission DT (2WD), DT (4WD): constant mesh with synchronized shuttle; HST (4WD): hydrostatic transmission (3-range) No. of Speeds 3 ranges DT (2WD), DT (4WD): 8 forward, 8 reverse; HST (4WD): 3-range Max Travel Speed (Forward) 11.2 mph DT (2WD), DT (4WD): 10.7 mph; HST (4WD): 11.5 mph Max Travel Speed (Reverse) 8.4 mph DT (2WD), DT (4WD): 10.7 mph; HST (4WD): 10.3 mph Clutch Not Published DT (2WD), DT (4WD): dry, single-stage; HST (4WD): n/a Differential Lock & Limited Slip Options Differential lock standard Rear differential lock, pedal operated ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydraulic power steering Integral type power steering Brakes Multi-plate wet disc Mechanical, wet disc type Seat Suspension & Adjustability Standard seat Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type Not Published Cast-iron front axle Front Axle Rating Not Published Not Published Drawbar Capacity 1,100 lb 730 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 101.8 in (without 3-point hitch) DT (2WD): 110.6 in; DT (4WD), HST (4WD): 108.5 in (without 3-point hitch) Overall Width 53.7 in 55.1 in Wheelbase 65.6 in DT (2WD): 63.8 in; DT (4WD), HST (4WD): 63.4 in Ground Clearance 14.6 in DT (2WD): 13.6 in; DT (4WD), HST (4WD): 13.4 in Min. Turn Radius without Brakes 6.9 ft (with brake applied) DT (2WD): 7.9 ft; DT (4WD), HST (4WD): 8.2 ft (with brake applied) Height to Top of ROPS 88.4 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1,830 lb DT (2WD): 2,601 lb; DT (4WD): 2,811 lb; HST (4WD): 2,833 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial, R14 R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 7-12 DT (2WD): 5.0-15; DT (4WD), HST (4WD): 7.2-16 R1 Agricultural - Rear 12.4-16 11.2-24 R3 Turf - Front 24x8.50-14 DT (2WD): 23X8.50-12; DT (4WD), HST (4WD): 25X8.50-14 R3 Turf - Rear 13.6-16 13.6-16 R4 Industrial - Front 23X8.50-14 / 25X8.50-14 DT (2WD): Not Applicable; DT (4WD), HST (4WD): 27X8.50-15 R4 Industrial - Rear 12.4-16 / 15-19.5 DT (2WD): Not Applicable; DT (4WD), HST (4WD): 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System LA535: 2-lever quick coupler, standard; Swift-Tach, optional Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Loader Model LA535 LA526 Loader Lift Height 84 in LA526: 94.8 in Loader Lift Capacity (Full Height) 1,067 lb LA526: 1,096 lb Loader Breakout Force 2,245 lb Not Published ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit
