▶ EngineEngine Manufacturer Kubota Yanmar Engine Model D1305-E4-D36R (LX2620HSD); D1305-E4-D26Q (LX2620HSDC); D1305-E4-D36R (LX2620SUHSD) 3TNE74 Engine Type Indirect injection, vertical, water-cooled, 4-cycle diesel 3-cylinder liquid-cooled diesel, indirect injection No. of Cylinders 3 3 Displacement 77.0 in³ 61.4 in³ Rated Engine Speed 2500 rpm 3000 rpm Engine Power (Gross) 23.3 hp 23 hp PTO Power 19.4 hp 17.7 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Pressurized radiator Liquid-cooled Air Cleaner 4.5 in paper filter with dual filter Dry type with safety element Fuel System Indirect injection Indirect injection, in-line fuel pump with solenoid shutoff Alternator Not Published 20 A ▶ HydraulicsPump Type Dual pump Not Published Implement Flow Not Published 3 gpm Steering Flow Not Published 2.5 gpm Total Hydraulic Flow 8.7 gpm 5.5 gpm Overall Hydraulic Pump Flow 8.7 gpm 5.5 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 7.1 gal (LX2620HSD); 8.5 gal (LX2620HSDC); 7.1 gal (LX2620SUHSD) 5.0 gal Coolant Capacity 4.5 qt (LX2620HSD); 5.7 qt (LX2620HSDC); 4.5 qt (LX2620SUHSD) 3.2 qt Crankcase Capacity 4.2 qt 2.2 qt Transmission / Hydraulic System Capacity 4.0 gal 3.4 gal Front Axle Fluid Capacity 5.0 qt 2.6 qt ▶ PTO & HitchPTO Type Independent Independent, wet disk clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability 2500 rpm (LX2620HSD); 2500 rpm (LX2620HSDC); optional (LX2620SUHSD) Standard, 2100 rpm Category, 3-Point Hitch Category I Category 1 Hitch Lift Capacity 2,139 lb Not Published Hitch Lift Capacity (at 24”) 1,676 lb 701 lb Lift Control Type Position control valve Not Published ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (HST), 3 ranges 2-range hydrostatic No. of Speeds 3 ranges Infinite forward and reverse, 2 ranges Max Travel Speed (Forward) 11.2 mph 8.4 mph Max Travel Speed (Reverse) 8.4 mph 6.3 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Differential lock standard Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post fixed ROPS; four-wheel drive Steering Hydrostatic power steering Power steering Brakes Multi-plate wet disc Wet disk Seat Suspension & Adjustability LX2620HSD, LX2620HSDC: deluxe seat, adjustable suspension; LX2620SUHSD: standard seat, normal suspension Not Published Front Axle Type Not Published MFWD, standard, all ranges, on-the-go engagement Front Axle Rating Not Published 3,120 lb Drawbar Capacity 1,100 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 53.7 in 47.2 in Wheelbase 65.6 in 57.1 in Ground Clearance 14.6 in 7.7 in (front axle) Min. Turn Radius without Brakes 6.9 ft (with brake applied) 88.6 in (MFWD off) Height to Top of ROPS 88.4 in 77.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 84.6 in Not Published Overall Length 101.8 in (LX2620HSD); 103.9 in (LX2620HSDC); 101.8 in (LX2620SUHSD) (without 3-point hitch) (all with R1 tires) 104.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,775 lb (LX2620HSD); 2,249 lb (LX2620HSDC); 1,775 lb (LX2620SUHSD) 1,400 lb (with all fluids) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial (R14 hybrid also offered) 18x8.5-10 front and 26x12.00-12 rear; R1 standard, R3 optional R1 Agricultural - Front 180/85D12 18x8.5-10 R1 Agricultural - Rear 320/85D16 26x12.00-12 R3 Turf - Front 24x8.50-14 18x8.5-10 R3 Turf - Rear 13.6-16 26x12.00-12 R4 Industrial - Front 23x8.5-14, 23x8.5-12 or 25x8.5-14 18x8.50-10 R4 Industrial - Rear 12.4-16, 14-17.5 or 15-19.5 26x12.00-12 ▶ Loader & AttachmentsQuick Attach Loader System LA535: 2-lever quick coupler standard; Swift-tach optional Not Published Loader Model LA535 210 Loader Lift Height LA535: 84 in (at pivot pin) 210: 68.5 in (at pivot pin) Loader Lift Capacity (Full Height) LA535: 1,067 lb (at pivot pin) 210: 622 lb (to max height at pivot point) Loader Breakout Force Not Published 210: 1,577 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published
