▶ EngineEngine Manufacturer Kubota Engine Model D1305-E4-D36R (LX2620HSD); D1305-E4-D26Q (LX2620HSDC); D1305-E4-D36R (LX2620SUHSD) Engine Type Indirect injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 3 Displacement 77.0 in³ Rated Engine Speed 2500 rpm Engine Power (Gross) 23.3 hp PTO Power 19.4 hp Engine Emissions Constraints Not Published Cooling System Type Pressurized radiator Air Cleaner 4.5 in paper filter with dual filter Fuel System Indirect injection Alternator Not Published ▶ HydraulicsPump Type Dual pump Implement Flow Not Published Steering Flow Not Published Total Hydraulic Flow 8.7 gpm Overall Hydraulic Pump Flow 8.7 gpm Hydraulic System Type Open center Rear Remote Hydraulic Flow Not Published No. of Standard Remote Valves Not Published No. of Optional Remote Valves Not Published ▶ Fluid CapacityFuel Tank Capacity 7.1 gal (LX2620HSD); 8.5 gal (LX2620HSDC); 7.1 gal (LX2620SUHSD) Coolant Capacity 4.5 qt (LX2620HSD); 5.7 qt (LX2620HSDC); 4.5 qt (LX2620SUHSD) Crankcase Capacity 4.2 qt Transmission / Hydraulic System Capacity 4.0 gal Front Axle Fluid Capacity 5.0 qt ▶ PTO & HitchPTO Type Independent PTO Rear 540 rpm Mid-PTO Availability 2500 rpm (LX2620HSD); 2500 rpm (LX2620HSDC); optional (LX2620SUHSD) Category, 3-Point Hitch Category I Hitch Lift Capacity 2,139 lb Hitch Lift Capacity (at 24”) 1,676 lb Lift Control Type Position control valve ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (HST), 3 ranges No. of Speeds 3 ranges Max Travel Speed (Forward) 11.2 mph Max Travel Speed (Reverse) 8.4 mph Clutch Not Published Differential Lock & Limited Slip Options Differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Steering Hydrostatic power steering Brakes Multi-plate wet disc Seat Suspension & Adjustability LX2620HSD, LX2620HSDC: deluxe seat, adjustable suspension; LX2620SUHSD: standard seat, normal suspension Front Axle Type Not Published Front Axle Rating Not Published Drawbar Capacity 1,100 lb ▶ Dimensions & ManeuverabilityOverall Width 53.7 in Wheelbase 65.6 in Ground Clearance 14.6 in Min. Turn Radius without Brakes 6.9 ft (with brake applied) Height to Top of ROPS 88.4 in Height to Top of ROPS (folded) Not Published Height to Top of Cab Model 84.6 in Overall Length 101.8 in (LX2620HSD); 103.9 in (LX2620HSDC); 101.8 in (LX2620SUHSD) (without 3-point hitch) (all with R1 tires) ▶ WeightTractor Weight (Base) 1,775 lb (LX2620HSD); 2,249 lb (LX2620HSDC); 1,775 lb (LX2620SUHSD) Weight with ROPS and Loader Not Published Weight with Cab and Loader Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial (R14 hybrid also offered) R1 Agricultural - Front 180/85D12 R1 Agricultural - Rear 320/85D16 R3 Turf - Front 24x8.50-14 R3 Turf - Rear 13.6-16 R4 Industrial - Front 23x8.5-14, 23x8.5-12 or 25x8.5-14 R4 Industrial - Rear 12.4-16, 14-17.5 or 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System LA535: 2-lever quick coupler standard; Swift-tach optional Loader Model LA535 Loader Lift Height LA535: 84 in (at pivot pin) Loader Lift Capacity (Full Height) LA535: 1,067 lb (at pivot pin) Loader Breakout Force Not Published ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours
