▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1305-E4-D36R (LX2620HSD); D1305-E4-D26Q (LX2620HSDC); D1305-E4-D36R (LX2620SUHSD) D1005 Engine Type Indirect injection, vertical, water-cooled, 4-cycle diesel Liquid-cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 77.0 in³ 61.1 in³ Rated Engine Speed 2500 rpm 3200 rpm Engine Power (Gross) 23.3 hp 23.3 hp PTO Power 19.4 hp 19.2 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Pressurized radiator Water with pressurized radiator, reverse air-flow design Air Cleaner 4.5 in paper filter with dual filter Dry element Fuel System Indirect injection Direct injection Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Dual pump Open center tandem pump gear type Implement Flow Not Published 5.2 gpm Steering Flow Not Published 1.0 gpm Total Hydraulic Flow 8.7 gpm 6.2 gpm Overall Hydraulic Pump Flow 8.7 gpm 6.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None (2-valve rear remote coupler optional) No. of Optional Remote Valves Not Published 2 (optional; ISO 7241-1 series A or B) ▶ Fluid CapacityFuel Tank Capacity 7.1 gal (LX2620HSD); 8.5 gal (LX2620HSDC); 7.1 gal (LX2620SUHSD) 6.6 gal Coolant Capacity 4.5 qt (LX2620HSD); 5.7 qt (LX2620HSDC); 4.5 qt (LX2620SUHSD) 3.5 qt Crankcase Capacity 4.2 qt 4.2 qt Transmission / Hydraulic System Capacity 4.0 gal 3.0 gal Front Axle Fluid Capacity 5.0 qt 3.8 qt ▶ PTO & HitchPTO Type Independent Live independent PTO (with hydraulic clutch) PTO Rear 540 rpm STD (540 rpm) Mid-PTO Availability 2500 rpm (LX2620HSD); 2500 rpm (LX2620HSDC); optional (LX2620SUHSD) STD (2500 rpm) Category, 3-Point Hitch Category I SAE Category I Hitch Lift Capacity 2,139 lb 1,213 lb Hitch Lift Capacity (at 24”) 1,676 lb 680 lb Lift Control Type Position control valve Quarter-inching valve ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (HST), 3 ranges Hydrostatic transmission No. of Speeds 3 ranges 2 Range (Low-High) Max Travel Speed (Forward) 11.2 mph 8.4 mph Max Travel Speed (Reverse) 8.4 mph 6.5 mph Clutch Not Published None (HST) Differential Lock & Limited Slip Options Differential lock standard Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS Steering Hydrostatic power steering Hydrostatic type power steering Brakes Multi-plate wet disc Mechanical, wet disc type Seat Suspension & Adjustability LX2620HSD, LX2620HSDC: deluxe seat, adjustable suspension; LX2620SUHSD: standard seat, normal suspension High-back seat with armrests; fore/aft slide and backrest-tilt adjustment Front Axle Type Not Published 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity 1,100 lb Max. drawbar load @ hitch: 550 lb ▶ Dimensions & ManeuverabilityOverall Width 53.7 in 45.1 in Wheelbase 65.6 in 55.1 in Ground Clearance 14.6 in 6.5 in Min. Turn Radius without Brakes 6.9 ft (with brake applied) 7.5 ft Height to Top of ROPS 88.4 in 83.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 84.6 in Not Published Overall Length 101.8 in (LX2620HSD); 103.9 in (LX2620HSDC); 101.8 in (LX2620SUHSD) (without 3-point hitch) (all with R1 tires) 95.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,775 lb (LX2620HSD); 2,249 lb (LX2620HSDC); 1,775 lb (LX2620SUHSD) 1,521 lb (with ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial (R14 hybrid also offered) R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 180/85D12 18X8.5-10 R1 Agricultural - Rear 320/85D16 26X12-12 R3 Turf - Front 24x8.50-14 18X8.5-10 R3 Turf - Rear 13.6-16 26X12-12 R4 Industrial - Front 23x8.5-14, 23x8.5-12 or 25x8.5-14 18X8.5-10 R4 Industrial - Rear 12.4-16, 14-17.5 or 15-19.5 26X12-12 ▶ Loader & AttachmentsQuick Attach Loader System LA535: 2-lever quick coupler standard; Swift-tach optional Swift-Tach Loader (LA344S - Two Lever Quick Attach Bucket) Loader Model LA535 LA344S (standard, quick attach); LA344 (pin-on option) Loader Lift Height LA535: 84 in (at pivot pin) 71.0 in (at pivot pin) Loader Lift Capacity (Full Height) LA535: 1,067 lb (at pivot pin) 739 lb (LA344 pin-on); 613 lb (LA344S quick attach) Loader Breakout Force Not Published 1,407 lbf (LA344 pin-on); 1,286 lbf (LA344S quick attach) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
