▶ EngineEngine Manufacturer Kubota Kubota Engine Model V1505-CR-TE5-D36R1 D1305-E3-D22 Engine Type E-CDIS, liquid cooled, 4-cylinder, diesel 3-cylinder, liquid-cooled diesel (E-TVCS) No. of Cylinders 4 3 Displacement 91.5 in³ 77.0 in³ Rated Engine Speed 2500 rpm 2800 rpm Engine Power (Gross) 30.8 hp 27.2 hp PTO Power 27 hp 21 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Pressurized radiator Liquid-cooled, pressurized radiator Air Cleaner 6.0 in Dual paper element Not Published Fuel System Common Rail System (CRS) Indirect injection Alternator 60 A, 12 V 14.5 A, 12 V ▶ HydraulicsPump Type Dual pump Dual pump Implement Flow 5.0 gpm 4.7 gpm Steering Flow 3.7 gpm 3.6 gpm Total Hydraulic Flow 8.7 gpm 8.3 gpm Overall Hydraulic Pump Flow 8.7 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None 1 or 2 No. of Optional Remote Valves Optional, up to 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 7.1 gal 6.9 gal Coolant Capacity 4.5 qt 4.1 qt Crankcase Capacity 5.0 qt 3.7 qt Transmission / Hydraulic System Capacity 4.0 gal 4.0 gal Front Axle Fluid Capacity 5.0 qt Not Published ▶ PTO & HitchPTO Type Independent Live PTO Rear 540 rpm 540/960 rpm Mid-PTO Availability 2500 rpm 2500 rpm (USA No. 5, Kubota 10-tooth) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,139 lb 1,356 lb Hitch Lift Capacity (at 24”) 1,676 lb 1,058 lb Lift Control Type Position control valve Quarter inching valve ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission Main-hydrostatic transmission, 3-range No. of Speeds 3 ranges 3-range (3 forward, 3 reverse) Max Travel Speed (Forward) 13.6 mph 12.6 mph Max Travel Speed (Reverse) 10.3 mph 10.0 mph Clutch Not Applicable Not Published Differential Lock & Limited Slip Options Differential lock standard Differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (sunshade optional) Steering Hydraulic power steering Integral type power steering Brakes Multi-plate wet disc Wet disk type Seat Suspension & Adjustability Deluxe high-back suspension seat Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,100 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 53.7 in 49.0 in Wheelbase 65.6 in 61.5 in Ground Clearance 14.6 in 12.8 in Min. Turn Radius without Brakes 6.9 ft (with brake applied) 6.9 ft (with brake applied) Height to Top of ROPS 88.4 in 85.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable Not Published Overall Length 101.8 in (without 3-point hitch) 95.1 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 2,072 lb 1,554 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial, R14 Standard farm 7-12 front, 11.2-16 rear R1 Agricultural - Front 7-12 7-12 R1 Agricultural - Rear 12.4-16 11.2-16 R3 Turf - Front 24x8.50-14 Not Published R3 Turf - Rear 13.6-16 Not Published R4 Industrial - Front 23X8.50-14 / 25X8.50-14 23x8.50-12 R4 Industrial - Rear 12.4-16 / 15-19.5 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System LA535: 2-lever quick coupler, standard; Swift-Tach, optional Not Published Loader Model LA535 LA364 Loader Lift Height 84 in LA364: 78.5 in (at pivot pin) Loader Lift Capacity (Full Height) 1,067 lb LA364: 952 lb (at pivot pin) Loader Breakout Force 2,245 lb LA364: 2,144 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
