▶ EngineEngine Manufacturer Kubota Kubota Engine Model V1505-CR-TE5-D36Q1 Not Published Engine Type E-CDIS, liquid cooled, 4-cylinder, diesel Not Published No. of Cylinders 4 3 Displacement 91.5 in³ 91.5 in³ Rated Engine Speed 2500 rpm 2800 rpm Engine Power (Gross) 30.8 hp 30 hp PTO Power 27 hp F (2WD gear), DT (4WD gear): 25 hp; HST (4WD): 23.5 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Pressurized radiator Liquid-cooled Air Cleaner 6.0 in Dual paper element Not Published Fuel System Common Rail System (CRS) Indirect injection Alternator 60 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Dual pump Not Published Implement Flow 5.0 gpm 6.5 gpm Steering Flow 3.7 gpm 4.0 gpm Total Hydraulic Flow 8.7 gpm 10.5 gpm (6.5 + 4.0, computed) Overall Hydraulic Pump Flow 8.7 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None Not Published No. of Optional Remote Valves Optional, up to 2 Up to 3 ▶ Fluid CapacityFuel Tank Capacity 8.4 gal 9.0 gal Coolant Capacity 4.5 qt Not Published Crankcase Capacity 5.0 qt Not Published Transmission / Hydraulic System Capacity 4.0 gal F (2WD): 7.1 gal; DT (4WD): 7.3 gal; HST (4WD): 6.2 gal Front Axle Fluid Capacity 5.0 qt 4.8 qt ▶ PTO & HitchPTO Type Independent F (2WD gear), DT (4WD gear): transmission-driven with overrunning clutch; HST (4WD): live-continuous with overrunning clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability 2500 rpm Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,139 lb 1,998 lb Hitch Lift Capacity (at 24”) 1,676 lb 1,435 lb Lift Control Type Position control valve Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission Not Published No. of Speeds 3 ranges F (2WD gear), DT (4WD gear): 8F/4R; HST (4WD): 3-range Max Travel Speed (Forward) 13.6 mph F (2WD gear), DT (4WD gear): 13.7 mph; HST (4WD): 14.7 mph Max Travel Speed (Reverse) 10.3 mph F (2WD gear), DT (4WD gear): 4.9 mph; HST (4WD): 13.2 mph Clutch Not Published F (2WD gear), DT (4WD gear): dry-type single stage; HST (4WD): dry-type single stage Differential Lock & Limited Slip Options Differential lock standard Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Foldable ROPS (standard on all models) Steering Hydraulic power steering Integral type power steering Brakes Multi-plate wet disc Wet disc type Seat Suspension & Adjustability Deluxe high-back suspension seat Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,100 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 53.7 in 51.4 in Wheelbase 65.6 in 63.3 in Ground Clearance 14.6 in F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.4 in Min. Turn Radius without Brakes 6.9 ft (with brake applied) F (2WD gear): 7.9 ft; DT (4WD gear), HST (4WD): 8.2 ft (with brake applied) Height to Top of ROPS Not Published 85.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 84.6 in Not Published Overall Length 103.9 in (without 3-point hitch) F (2WD gear): 110.6 in; DT (4WD gear), HST (4WD): 106.5 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 2,557 lb F (2WD gear): 2,359 lb; DT (4WD gear): 2,536 lb; HST (4WD): 2,600 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial, R14 F (2WD gear): 5-15 front, 11.2-24 rear; DT (4WD gear), HST (4WD): 7-16 front, 11.2-24 rear R1 Agricultural - Front 7-12 F (2WD gear): 5-15; DT (4WD gear), HST (4WD): 7-16 R1 Agricultural - Rear 12.4-16 11.2-24 R3 Turf - Front 24x8.50-14 2WD: 23x8.50-12; 4WD: 25x8.50-14 R3 Turf - Rear 13.6-16 13.6-16 R4 Industrial - Front 23X8.50-14 27x8.50-15 (4WD) R4 Industrial - Rear 12.4-16 15-19.5 R4 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System LA535: 2-lever quick coupler, standard; Swift-Tach, optional Not Published Loader Model LA535 LA463 Loader Lift Height 84 in LA463: 95.3 in (at pivot pin) Loader Lift Capacity (Full Height) 1,067 lb LA463: 1,142 lb (at pivot pin) Loader Breakout Force 2,245 lb LA463: 1,858 lbf (at 19.7 in) (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
