▶ EngineEngine Manufacturer Kubota Kubota Engine Model V1505-CR-TE5-D36Q1 D1803-CR-E4-GL2 Engine Type E-CDIS, liquid cooled, 4-cylinder, diesel Liquid-cooled, 4-cycle multi valve, diesel, Naturally Aspirated No. of Cylinders 4 3 Displacement 91.5 in³ 111.4 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 30.8 hp 37 hp PTO Power 27 hp 28 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Pressurized radiator Liquid-cooled Air Cleaner 6.0 in Dual paper element Dry paper, dual element Fuel System Common Rail System (CRS) Electronic CRS (Common Rail System) Alternator 60 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Dual pump Tandem pump - gear type Implement Flow 5.0 gpm 8.1 gpm Steering Flow 3.7 gpm 4.7 gpm Total Hydraulic Flow 8.7 gpm 12.8 gpm Overall Hydraulic Pump Flow 8.7 gpm 12.8 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 None standard (up to 3 optional) No. of Optional Remote Valves Optional, up to 2 Optional, up to 3 (double-acting valve or float detent valve options, any position) ▶ Fluid CapacityFuel Tank Capacity 8.4 gal 13.5 gal Coolant Capacity 4.5 qt 7.9 qt Crankcase Capacity 5.0 qt 7.1 qt Transmission / Hydraulic System Capacity 4.0 gal 11.1 gal Front Axle Fluid Capacity 5.0 qt 6.9 qt ▶ PTO & HitchPTO Type Independent Live independent (hydraulic clutch) PTO Rear 540 rpm 540 rpm @ 2476 engine rpm Mid-PTO Availability 2500 rpm Optional Category, 3-Point Hitch Category I SAE Category 1 Hitch Lift Capacity 2139 lb 3,750 lb Hitch Lift Capacity (at 24”) 1676 lb 2646 lb Lift Control Type Position control valve Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission Hydrostatic No. of Speeds 3 ranges 3-Range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) 13.6 mph 16.5 mph Max Travel Speed (Reverse) 10.3 mph 14.9 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Differential lock standard Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydraulic power steering Hydrostatic power steering Brakes Multi-plate wet disc Wet disc type, mechanically activated Seat Suspension & Adjustability Deluxe high-back suspension seat Deluxe suspension seat with swivel (standard); Air-Ride seat (optional) Front Axle Type Not Published 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity 1100 lb 1,433 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 103.9 in (without 3-point hitch) 115.0 in (without 3-point hitch) Overall Width 53.7 in 59.8 in Wheelbase 65.6 in 71.1 in Ground Clearance 14.6 in 13.5 in Min. Turn Radius without Brakes 6.9 ft (with brake applied) 8.9 ft (with brake applied) Height to Top of ROPS Not Published 97.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 84.6 in Not Published ▶ WeightTractor Weight (Base) 2557 lb 3505 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial, R14 R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 7.0-12 7.0-16 R1 Agricultural - Rear 12.4-16 12.4-24 R3 Turf - Front 24x8.50-14 27x10.50-15 R3 Turf - Rear 13.6-16 41x18LL-16.1 R4 Industrial - Front 23X8.50-14 10-16.5 R4 Industrial - Rear 12.4-16 420/70-24 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA535 - 2 Lever Quick Coupler (STD); Swift-tach (OPT)) LA555: Mechanical 2-Lever Quick Coupler (standard); LA805: Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) Loader Model LA535 LA555 or LA805 Loader Lift Height 84 in LA555: 96.4 in; LA805: 104.7 in Loader Lift Capacity (Full Height) 1067 lb LA555: 1190 lb; LA805: 1715 lb Loader Breakout Force 2245 lb LA555: 2030 lb; LA805: 2549 lb (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit
