▶ EngineEngine Manufacturer Kubota YANMAR Engine Model V1505-CR-TE5-D36Q1 3TNV88C-MLST Engine Type E-CDIS, liquid cooled, 4-cylinder, diesel 3-cylinder, liquid-cooled, diesel, naturally aspirated, CRDI No. of Cylinders 4 3 Displacement 91.5 in³ 100.2 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 30.8 hp 31.7 hp PTO Power 27 hp 26.2 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Pressurized radiator Liquid-cooled Air Cleaner 6.0 in Dual paper element Dry Fuel System Common Rail System (CRS) CRDI (common rail direct injection) Alternator 60 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Dual pump Gear pump Implement Flow 5.0 gpm 6.7 gpm Steering Flow 3.7 gpm 5.0 gpm Total Hydraulic Flow 8.7 gpm 11.7 gpm Overall Hydraulic Pump Flow 8.7 gpm 11.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None 1 pair No. of Optional Remote Valves Optional, up to 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 8.4 gal 10.6 gal Coolant Capacity 4.5 qt Not Published Crankcase Capacity 5.0 qt Not Published Transmission / Hydraulic System Capacity 4.0 gal Not Published Front Axle Fluid Capacity 5.0 qt Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability 2500 rpm Available (option) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,139 lb 1,808 lb Hitch Lift Capacity (at 24”) 1,676 lb 1,433 lb Lift Control Type Position control valve Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission HST No. of Speeds 3 ranges 3 ranges Max Travel Speed (Forward) 13.6 mph Not Published Max Travel Speed (Reverse) 10.3 mph Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Differential lock standard Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydraulic power steering Hydrostatic power steering Brakes Multi-plate wet disc Wet, multi-disc Seat Suspension & Adjustability Deluxe high-back suspension seat Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,100 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 53.7 in 66 in Wheelbase 65.6 in 69 in Ground Clearance 14.6 in Not Published Min. Turn Radius without Brakes 6.9 ft (with brake applied) 11.5 ft (3.5 m) Height to Top of ROPS Not Published 95 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 84.6 in Not Published Overall Length 103.9 in (without 3-point hitch) 125 in (frame to link) ▶ WeightTractor Weight (Base) 2,557 lb 3,254 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial, R14 Ag, Industrial, VT and Turf; VT same size as Industrial R1 Agricultural - Front 7-12 7-14 R1 Agricultural - Rear 12.4-16 11.2-24 R3 Turf - Front 24x8.50-14 25x8.50-14 R3 Turf - Rear 13.6-16 41x14.00-20 R4 Industrial - Front 23X8.50-14 27x8.50-15 R4 Industrial - Rear 12.4-16 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System LA535: 2-lever quick coupler, standard; Swift-Tach, optional LL3003: ISO 24410 Quick Attaching Coupler Loader Model LA535 LL3003, LL3004 Loader Lift Height 84 in LL3003, LL3004: 94.3 in Loader Lift Capacity (Full Height) 1,067 lb LL3003, LL3004: 2,063 lb (at pivot pin, maximum height) Loader Breakout Force 2,245 lb LL3003, LL3004: 3,723 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Two-year bumper to bumper; six-year limited powertrain ▶ ITC Company AccessoriesAccessories that fit None tagged yet
