▶ EngineEngine Manufacturer Kubota TYM Engine Model V1505-CR-TE5-D36Q1 T1700N3 Engine Type E-CDIS, liquid cooled, 4-cylinder, diesel 3-cylinder, naturally aspirated diesel No. of Cylinders 4 3 Displacement 91.5 in³ 104.5 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 30.8 hp 30 hp PTO Power 27 hp 25 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Pressurized radiator Not Published Air Cleaner 6.0 in Dual paper element Dry element Fuel System Common Rail System (CRS) IDI (indirect injection) Alternator 60 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Dual pump Dual gear pump Implement Flow 5.0 gpm 7.7 gpm Steering Flow 3.7 gpm 4.2 gpm Total Hydraulic Flow 8.7 gpm 11.9 gpm Overall Hydraulic Pump Flow 8.7 gpm 11.9 gpm Hydraulic System Type Open center Dual gear pump Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None Loader: 2 / Rear: 0 No. of Optional Remote Valves Optional, up to 2 Up to 4 ▶ Fluid CapacityFuel Tank Capacity 8.4 gal 7.1 gal Coolant Capacity 4.5 qt 5.3 qt Crankcase Capacity 5.0 qt 4.5 qt Transmission / Hydraulic System Capacity 4.0 gal 3015R: 9 gal; 3015H: 9.8 gal Front Axle Fluid Capacity 5.0 qt 6.8 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability 2500 rpm Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,139 lb 3,306 lb Hitch Lift Capacity (at 24”) 1,676 lb 2,425 lb Lift Control Type Position control valve Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission 3015R: Synchromesh; 3015H: HST No. of Speeds 3 ranges 3015R: F12 x R12; 3015H: 3-Range Max Travel Speed (Forward) 13.6 mph 3015R: 14.4 mph; 3015H: 18.8 mph Max Travel Speed (Reverse) 10.3 mph 3015R: 14.3 mph; 3015H: 18.7 mph Clutch Not Published 3015R: Dry single plate; 3015H: None (HST) Differential Lock & Limited Slip Options Differential lock standard Differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydraulic power steering Hydrostatic power steering Brakes Multi-plate wet disc Wet, multi-disc Seat Suspension & Adjustability Deluxe high-back suspension seat Suspension seat Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,100 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 53.7 in 56.3 in Wheelbase 65.6 in 65.7 in Ground Clearance 14.6 in 14.4 in Min. Turn Radius without Brakes 6.9 ft (with brake applied) L: 124.8 in; R: 121.3 in Height to Top of ROPS Not Published 97.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 84.6 in Not Published Overall Length 103.9 in (without 3-point hitch) 120.9 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,557 lb 3015R: 3,183 lb; 3015H: 3,163 lb Weight with ROPS and Loader Not Published HST: 4,171 lb (3,163 + 1,008, computed); Gear: 4,191 lb (3,183 + 1,008, computed) Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural 8-16 / 12.4-24; R3 Turf 27x8.5-15 6PR / 41x14.00 4PR; R4 Industrial 10-16.5 6PR / 420/70-24 6PR R1 Agricultural - Front 7-12 8-16 R1 Agricultural - Rear 12.4-16 12.4-24 R3 Turf - Front 24x8.50-14 27x8.5-15, 6PR R3 Turf - Rear 13.6-16 41x14.00, 4PR R4 Industrial - Front 23X8.50-14 10-16.5, 6PR R4 Industrial - Rear 12.4-16 420/70-24, 6PR ▶ Loader & AttachmentsQuick Attach Loader System LA535: 2-lever quick coupler, standard; Swift-Tach, optional BL150: Quick attach mechanism Loader Model LA535 BL150 Loader Lift Height 84 in BL150: 104.9 in Loader Lift Capacity (Full Height) 1,067 lb BL150: 2,200 lb (at pivot pin) Loader Breakout Force 2,245 lb BL150: 3,422 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Basic 24 months or 2,000 hours, parts and labor; non-commercial, 20 to 70 engine hp: powertrain 72 months or 3,000 hours; loaders, backhoes and mid-mount mowers 12 months ▶ ITC Company AccessoriesAccessories that fit
