▶ EngineEngine Manufacturer Kubota KIOTI Engine Model V1505-CR-TE5-D40R5 CK3520, CK3520H: 3H-TM4A; CK3520SE, CK3520SEH, CK3520SEH CAB: 3H-TM4B Engine Type Turbocharged, direct injection, liquid-cooled diesel 3-cylinder, in-line, liquid-cooled diesel No. of Cylinders 4 3 Displacement 91.4 in³ 111.4 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 34.9 hp 34.9 hp PTO Power 28.7 hp CK3520, CK3520SE: 30.9 hp; CK3520H, CK3520SEH, CK3520SEH CAB: 28.9 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Pressurized radiator Liquid-cooled Air Cleaner 6 in paper filter (with dual element) Dry element Fuel System Direct injection Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Dual pump Gear Implement Flow 5.4 gpm CK3520, CK3520H: 7.14 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 6.86 gpm Steering Flow 4.1 gpm CK3520, CK3520H: 4.59 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 4.46 gpm Total Hydraulic Flow 9.5 gpm CK3520, CK3520H: 11.73 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 11.33 gpm Overall Hydraulic Pump Flow 9.5 gpm CK3520, CK3520H: 11.73 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 11.33 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None CK3520, CK3520H: None; CK3520SE, CK3520SEH, CK3520SEH CAB: 2 No. of Optional Remote Valves Optional, up to 2 CK3520, CK3520H: 2 ▶ Fluid CapacityFuel Tank Capacity 8.5 gal 9.0 gal Coolant Capacity Not Published 0.89 gal Crankcase Capacity 5.0 qt 1.6 gal Transmission / Hydraulic System Capacity 5.5 gal 5.8 gal Front Axle Fluid Capacity 4.8 qt 1.6 gal ▶ PTO & HitchPTO Type Independent CK3520, CK3520H: Live; CK3520SE, CK3520SEH, CK3520SEH CAB: Independent PTO Rear 540 rpm 540 rpm (1-3/8 in, 6 splines) Mid-PTO Availability 2460 rpm Optional, 2,000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,535 lb 2,270 lb Hitch Lift Capacity (at 24”) 1,962 lb 1,631 lb Lift Control Type Position control valve Position control ▶ Transmission & DrivetrainTransmission Type HST (3 ranges) CK3520: Manual; CK3520H, CK3520SEH, CK3520SEH CAB: Hydrostatic; CK3520SE: Synchro shuttle No. of Speeds HST (3 ranges) CK3520: 9F/3R; CK3520H, CK3520SEH, CK3520SEH CAB: Infinite, 3 range; CK3520SE: 12F/12R Max Travel Speed (Forward) 17.0 mph CK3520: 14.64 mph; CK3520H, CK3520SEH, CK3520SEH CAB: 14.88 mph; CK3520SE: 15.53 mph Max Travel Speed (Reverse) 13.0 mph CK3520: 9.56 mph; CK3520H, CK3520SEH, CK3520SEH CAB: 10.41 mph; CK3520SE: 15.14 mph Clutch Not Published CK3520: dry, dual-stage; CK3520H, CK3520SE: dry, single-stage; CK3520SEH, CK3520SEH CAB: n/a (hydrostatic) Differential Lock & Limited Slip Options Standard Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Multi-plate wet disk Wet multi-disc Seat Suspension & Adjustability Deluxe suspension seat (high back, designed to absorb shock) Not Published Front Axle Type Not Published 4WD, manual engagement Front Axle Rating Not Published Not Published Drawbar Capacity 1,100 lb 1,433 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 116.1 in 120.9 in Overall Width 53.7 in 54.5 in Wheelbase 66.7 in 65.7 in Ground Clearance 8.9 in 13.4 in Min. Turn Radius without Brakes 7.5 ft (with brake applied) 107.5 in Height to Top of ROPS 88.2 in 92.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 85.6 in n/a (ROPS model) ▶ WeightTractor Weight (Base) 2,191 lb CK3520: 2,679 lb; CK3520H: 2,734 lb; CK3520SE: 2,906 lb; CK3520SEH: 2,921 lb; CK3520SEH CAB: 3,397 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial, R14 Front AG 7-16 (Turf 28x8.5-15/6, Industrial 27x8.5-15); Rear AG 11.2-24 (Turf 41x14-20/4, Industrial 15-19.5) R1 Agricultural - Front 180/85D12 7-16 R1 Agricultural - Rear 320/85D16 11.2-24 R3 Turf - Front 24x8.5-14 28x8.5-15/6 R3 Turf - Rear Not Published 41x14-20/4 R4 Industrial - Front 23x8.5-12 or 25x8.5-14 27x8.5-15 R4 Industrial - Rear 14-17.5 or 15-19.5 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System LA545: 2-lever quick coupler, standard; Swift-Tach, optional Not Published Loader Model LA545 KL4030; KL4030C Loader Lift Height 87.6 in 98.4 in (KL4030 and KL4030C loaders) Loader Lift Capacity (Full Height) 1,100 lb KL4030: 1,835 lb; KL4030C: 1,969 lb Loader Breakout Force Not Published KL4030: 3,464 lb; KL4030C: 2,989 lb ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Non-commercial: basic 24 months, powertrain 72 months, unlimited hours, parts and labor ▶ ITC Company AccessoriesAccessories that fit None tagged yet
