▶ PtoPTO Power 19.4 hp 13.7 hp Mid PTO (Type / RPM) 2500 RPM (LX2620), 2460 RPM (LX3520/LX4020, optional) Independent Rear PTO (Type / RPM) 540 RPM 540, 1000 ▶ HitchThree-Point Hitch Category Category I Category I Lift Capacity at 24 in Behind LX2620: 1,819 lbs; LX3520/LX4020: 1,962 lbs 1808 (820) lbs. (kg); 1411 (640) lbs. (kg); 1290 (585) lbs. (kg) ▶ EnginePTO Power 28.7 (21.4) HP (kW) 19.2 (14.3) HP (kW) Air Cleaner LX2620: 4.5 inch paper filter (with dual filter); LX3520/LX4020: 6 inch paper filter (with dual element) Dual paper element Engine Type Indirect injection, vertical, water-cooled, 4-cycle diesel and Direct injection, vertical, water-cooled, 4-cycle diesel with turbocharger E-TVCS, liquid cooled, 3-cylinder diesel Fuel System Common Rail (CRS) diesel Radial air flow Displacement 77 in³ 68.5 (1123) cu. in. (cc) No. of Cylinders 4 3 Rated Engine Speed 2500 rpm 2600 rpm Cooling System Type Pressurized radiator with radial air flow fan Liquid Cooled Engine Manufacturer Kubota Kubota Engine Power (Gross) 23.3 hp 21.9 (16.3) HP (kW) Alternator — 40 A Engine Emissions Constraints — Tier 4 ▶ WeightTractor Weight (Base) LX2620: 1,775 lbs; LX3520DTN: 2,154 lbs; LX3520: 2,191 lbs; LX4020: 2,624 lbs 1,404 lbs. Tractor Weight with Loader — 1,521 lbs. ▶ HydraulicsPump Type Dual pump Dual pump Pump Flow (Total) LX2620: 8.7 gpm (33.1 ℓ/min); LX3520: 9.1 gpm (34.5 ℓ/min); LX4020: 9.5 gpm (35.8 ℓ/min) 8.3 gpm / 31.4 l/min Total Hydraulic Flow 9.1 (34.5) gpm (l/min.) 7.0 (26.4) gpm (ℓ/min.) Hydraulic System Type Open center Open center System Operating Pressure Open center system 2500 psi Overall Hydraulic Pump Flow 9.1 (34.5) gpm (l/min.) 7.0 (26.4) gpm (ℓ/min.) Steering Flow — 2.6 gpm 9.8 lpm Implement Flow — 4.0 gpm Pump Flow (Steering) — 2.6 gpm (2.6 gals/min) Pump Flow (Implement) — 3P: 4.4 gpm (4.4 gals/min) Rear Remote Hydraulic Flow — Front & Rear outlet No. of Optional Remote Valves — 1 No. of Standard Remote Valves — 0 ▶ DimensionsWheelbase LX2620: 65.6 in.; LX3520: 61.0 in.; LX4020: 66.7 in. 61.4 in / 61.4 in Overall Width LX2620/LX4020: 53.7 in.; LX3520 Narrow: 39.4 in. 44.3 in / 44.3 in Overall Length LX2620: 101.8 in.; LX3520DTN: 98.2 in.; LX3520/LX4020: 101.6-103.9 in. (2580-103.9 in) 93.9 in / 93.9 in Ground Clearance LX2620: 14.6 in.; LX3520: 12.8 in.; LX3520 Narrow: 12.8 in.; LX4020: 8.9 in. 12 in / 12 in Height to Top of ROPS LX3520 Narrow: 56.7 in. (folded) 81.9" ▶ PTO & HitchPTO Rear 540 rpm 540, 1000 rpm PTO Type Independent Transmission driven with one way clutch Lift Control Type Position control valve Position control valve Hitch Lift Capacity 2348 (1065) lbs. (kg) 1653 (750) lbs. (kg) Mid-PTO Availability 2460 RPM 2500 rpm Category, 3-Point Hitch Category I Category I ▶ Tire OptionsR3 Turf - Rear 16.6-16 33x12.5-15 R3 Turf - Front 24x8.5-14 23x8.50-12 Tire Size & Options Front R1: 7-12; R4: 23×8.50-12; R4 large: 25×8.50-14; R14: 23×8.50-12; R14 large: 25×8.50-14; TURF: 24×8.50-14; Rear R1: 12.4-16; R4: 14-17.5; R14: 14-17.5; TURF: 13.6-16; R4 large: 15-19.5; R14 large: 15-19.5 — R4 Industrial - Rear 14-17.5 or 15-19.5 — R4 Industrial - Front 23x8.5-12 or 25x8.5-14 — R1 Agricultural - Rear 320/85D16 9.5-16 R1 Agricultural - Front 180/85D12 6-12 ▶ TransmissionNumber of Speeds 3 ranges (Low, Mid, High) 9 Forward, 3 Reverse Transmission Type HST (Hydrostatic) with 3 ranges Gear (9 Forward, 3 Reverse) ▶ Fluid CapacityCoolant Capacity LX2620: 4.5 qts (4.3 ℓ); LX3520/LX4020: 5.7 qts (5.4 ℓ) 4.0 (3.8) qts. (ℓ) Crankcase Capacity LX2620: 4.2 qts (4.0 ℓ); LX3520/LX4020: 5.0 qts (4.7 ℓ) 3.3 (3.1) qts. (ℓ) Fuel Tank Capacity LX2620: 7.1 gal (27 ℓ); LX3520/LX4020: 8.5 gal (32 ℓ) 6.1 gal. Transmission/Hydraulic Capacity LX2620: 4.0 gal (15 ℓ); LX3520/LX4020: 5.5 gal (21.0 ℓ) 3.3 gal / 12.5 l Transmission / Hydraulic System Capacity 5.5 (21.0) gal (ℓ) 3.3 (12.5) gal (ℓ) ▶ Loader & AttachmentsLoader Lift Height 87.6 (2226) in. (mm) 78.5" Quick Attach Loader System 2-Lever Quick Coupler (Standard); Swift-Tach (Optional) LA435 Swift-Tach Loader; 1-lever Quick Coupler (standard); 2-Lever Quick Coupler (optional) Loader Lift Capacity (Full Height) 1100 (499) lbs. (kg) 1,175 lbs. Loader Breakout Force — 2,146 lbf. ▶ Transmission & DrivetrainClutch N/A Dry single plate No. of Speeds HST (3 range) 9 Forward, 3 Reverse Transmission Type HST (3 ranges) Gear (9 Forward, 3 Reverse) Max Travel Speed (Forward) 17.0 (0-27.4) mph (km/h) 0-11.7 (0-18.8) mph (km/h) Max Travel Speed (Reverse) 13.0 (0-20.8) mph (km/h) 0-6.0 (0-9.6) mph (km/h) Differential Lock & Limited Slip Options Standard Standard ▶ Chassis, Steering & ControlsBrakes Multi-plate wet disk Multi-plate wet disc Steering Hydrostatic power steering Integral type power steering Seat Suspension & Adjustability Deluxe suspension seat (high back, designed to absorb shock) High-back seat (absorbs shock); NOTE: Deluxe seat with armrests and seat suspension listed for HST models only - not explicitly confirmed for B2401 gear-drive (DT) in spec sheet Front Axle Type — Cast-iron front axle Drawbar Capacity — 661.4 lb (660 lbs) ▶ Dimensions & ManeuverabilityWheelbase 66.7 (1695) in. (mm) 61.4 (1560) in. (mm) Overall Width 53.7 (1365) in. (mm) 44.3 (1125) in. (mm) Ground Clearance 12.8 (325) in. (mm) 12.0 (305) in. (mm) Height to Top of ROPS (folded) 56.7 (1440) in. (mm) — Min. Turn Radius without Brakes 7.5 (2.3) feet (m) Front drive disengaged 6.9 (2.1) feet (m) Overall Length with 3-Point Hitch 101.8 (2586) in. (mm) 93.9 in. Height to Top of ROPS — 83.9 in. ▶ Pricing, Financing & WarrantyWarranty Length & Coverage Full warranty: 2 years / 2,000 hours | Powertrain warranty: 6 years / 2,000 hours Full warranty: 2 years / 2,000 hours; Powertrain warranty: 6 years / 2,000 hours ▶ ITC Company AccessoriesAccessories that fit
