▶ EngineEngine Manufacturer Kubota Kubota Engine Model V1505-CR-TE5-D40R5 D1803-CR-E5 Engine Type Turbocharged, direct injection, liquid-cooled diesel Direct injection, vertical, water-cooled 4-cycle, diesel No. of Cylinders 4 3 Displacement 91.4 in³ 111.4 in³ Rated Engine Speed 2700 rpm 2700 rpm Engine Power (Gross) 34.9 hp 33 hp PTO Power 28.7 hp 26.1 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Pressurized radiator Water-cooled Air Cleaner 6 in paper filter (with dual element) Dry type, single element Fuel System Direct injection Direct injection Alternator Not Published 45 A, 12 V ▶ HydraulicsPump Type Dual pump Not Published Implement Flow 5.4 gpm 6.3 gpm Steering Flow 4.1 gpm 3.8 gpm Total Hydraulic Flow 9.5 gpm 10.1 gpm (6.3 + 3.8, computed) Overall Hydraulic Pump Flow 9.5 gpm 10.1 gpm (6.3 + 3.8, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None Not Published No. of Optional Remote Valves Optional, up to 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 8.5 gal 11.1 gal Coolant Capacity Not Published 6.3 qt Crankcase Capacity 5.0 qt 7.1 qt Transmission / Hydraulic System Capacity 5.5 gal 6.9 gal Front Axle Fluid Capacity 4.8 qt 4.8 qt ▶ PTO & HitchPTO Type Independent Live independent PTO with hydraulic clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability 2460 rpm Not Published Category, 3-Point Hitch Category I SAE Category I Hitch Lift Capacity 2,535 lb 1,998 lb Hitch Lift Capacity (at 24”) 1,962 lb 1,435 lb Lift Control Type Position control valve Position control ▶ Transmission & DrivetrainTransmission Type HST (3 ranges) Hydrostatic transmission (3-range) No. of Speeds HST (3 ranges) 3-range Max Travel Speed (Forward) 17.0 mph 14.1 mph Max Travel Speed (Reverse) 13.0 mph 12.7 mph Clutch Not Published Not Applicable Differential Lock & Limited Slip Options Standard Rear differential lock, pedal operated ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Integral type power steering Brakes Multi-plate wet disk Mechanical, wet disc type Seat Suspension & Adjustability Deluxe suspension seat (high back, designed to absorb shock) Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type Not Published Cast-iron front axle Front Axle Rating Not Published Not Published Drawbar Capacity 1,100 lb 730 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 116.1 in 108.5 in (without 3-point hitch) Overall Width 53.7 in 55.1 in Wheelbase 66.7 in 63.4 in Ground Clearance 8.9 in 13.4 in Min. Turn Radius without Brakes 7.5 ft (with brake applied) 8.2 ft (with brake applied) Height to Top of ROPS 88.2 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 85.6 in Not Published ▶ WeightTractor Weight (Base) 2,191 lb 2,778 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 180/85D12 7.2-16 R1 Agricultural - Rear 320/85D16 11.2-24 R3 Turf - Front 24x8.5-14 25X8.50-14 R3 Turf - Rear Not Published 13.6-16 R4 Industrial - Front 23x8.5-12 or 25x8.5-14 27X8.50-15 R4 Industrial - Rear 14-17.5 or 15-19.5 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System LA545: 2-lever quick coupler, standard; Swift-Tach, optional Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Loader Model LA545 LA526 Loader Lift Height 87.6 in 94.8 in Loader Lift Capacity (Full Height) 1,100 lb 1,144 lb Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
