▶ EngineEngine Manufacturer Kubota Kubota Engine Model V1505-CR-TE5-D40R5 D1803-CR-E4-GL2 Engine Type Turbocharged, direct injection, liquid-cooled diesel Naturally aspirated, multi-valve, liquid-cooled diesel No. of Cylinders 4 3 Displacement 91.4 in³ 111.4 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 34.9 hp 37 hp PTO Power 28.7 hp 28 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Pressurized radiator Liquid-cooled Air Cleaner 6 in paper filter (with dual element) Dry paper, dual element Fuel System Direct injection Electronic CRS (Common Rail System) Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Dual pump Tandem pump - gear type Implement Flow 5.4 gpm 9.4 gpm Steering Flow 4.1 gpm 4.7 gpm Total Hydraulic Flow 9.5 gpm 14.1 gpm Overall Hydraulic Pump Flow 9.5 gpm 14.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None None standard (up to 3 optional) No. of Optional Remote Valves Optional, up to 2 Optional, up to 3: double-acting valve or float detent valve, any position ▶ Fluid CapacityFuel Tank Capacity 8.5 gal 13.5 gal Coolant Capacity Not Published 7.9 qt Crankcase Capacity 5.0 qt 7.1 qt Transmission / Hydraulic System Capacity 5.5 gal 11.1 gal Front Axle Fluid Capacity 4.8 qt 6.9 qt ▶ PTO & HitchPTO Type Independent Live independent (hydraulic clutch) PTO Rear 540 rpm 540 rpm @ 2476 engine rpm Mid-PTO Availability 2460 rpm Optional Category, 3-Point Hitch Category I SAE Category I Hitch Lift Capacity 2,535 lb 3,750 lb Hitch Lift Capacity (at 24”) 1,962 lb 2,646 lb Lift Control Type Position control valve Position control ▶ Transmission & DrivetrainTransmission Type HST (3 ranges) Hydrostatic No. of Speeds HST (3 ranges) 3-Range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) 17.0 mph 16.5 mph Max Travel Speed (Reverse) 13.0 mph 14.9 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Standard Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Multi-plate wet disk Wet disc type, mechanically activated Seat Suspension & Adjustability Deluxe suspension seat (high back, designed to absorb shock) Suspension seat with swivel (standard); air-suspension seat (optional) Front Axle Type Not Published 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity 1,100 lb 1,433 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 116.1 in Not Published Overall Width 53.7 in 59.8 in Wheelbase 66.7 in 71.1 in Ground Clearance 8.9 in 13.5 in Min. Turn Radius without Brakes 7.5 ft (with brake applied) 8.9 ft (with brake applied) Height to Top of ROPS 88.2 in 97.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 85.6 in Not Published ▶ WeightTractor Weight (Base) 2,191 lb 3,483 lb (DT ROPS); 3,494 lb (GST ROPS); 3,505 lb (HST ROPS); 3,880 lb (HSTC cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 180/85D12 7.0-16 R1 Agricultural - Rear 320/85D16 12.4-24 R3 Turf - Front 24x8.5-14 27x10.50-15 R3 Turf - Rear Not Published 41x18LL-16.1 R4 Industrial - Front 23x8.5-12 or 25x8.5-14 10-16.5 R4 Industrial - Rear 14-17.5 or 15-19.5 420/70-24 ▶ Loader & AttachmentsQuick Attach Loader System LA545: 2-lever quick coupler, standard; Swift-Tach, optional LA555: 2-lever mechanical quick coupler (standard); LA805: 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Loader Model LA545 LA555 or LA805 Loader Lift Height 87.6 in LA555: 96.4 in; LA805: 104.7 in Loader Lift Capacity (Full Height) 1,100 lb LA555: 1,190 lb; LA805: 1,715 lb Loader Breakout Force Not Published LA555: 2,030 lb; LA805: 2,549 lb (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
