▶ EngineEngine Manufacturer Kubota LS Mtron Engine Model V1505-CR-TE5-D40R5 L3CRV-T5 Engine Type Turbocharged, direct injection, liquid-cooled diesel 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 4 3 Displacement 91.4 in³ 114.7 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 34.9 hp 35 hp PTO Power 28.7 hp Gear: 29.7 hp; HST: 28 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Pressurized radiator Liquid cooled Air Cleaner 6 in paper filter (with dual element) Replaceable primary and inner elements Fuel System Direct injection Electronically controlled common rail direct injection Alternator Not Published 70 A, 12 V ▶ HydraulicsPump Type Dual pump Gear Implement Flow 5.4 gpm 8.2 gpm Steering Flow 4.1 gpm Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow 9.5 gpm Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow 9.5 gpm Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None 1 No. of Optional Remote Valves Optional, up to 2 Up to 2 (second valve optional) ▶ Fluid CapacityFuel Tank Capacity 8.5 gal 10.5 gal Coolant Capacity Not Published 7.5 qt Crankcase Capacity 5.0 qt 5.8 qt Transmission / Hydraulic System Capacity 5.5 gal 8.5 gal Front Axle Fluid Capacity 4.8 qt 6.87 qt ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability 2460 rpm Standard (2000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,535 lb 1,808 lb Hitch Lift Capacity (at 24”) 1,962 lb 1,345 lb Lift Control Type Position control valve Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type HST (3 ranges) Gear: 12x12 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal No. of Speeds HST (3 ranges) Gear: 12F/12R; HST: 3-range Max Travel Speed (Forward) 17.0 mph Gear: 14.2 mph; HST: 14.8 mph Max Travel Speed (Reverse) 13.0 mph Gear: 13.63 mph; HST: 13.60 mph Clutch Not Published Gear: dry single disc (9.4 in); HST: n/a Differential Lock & Limited Slip Options Standard Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Multi-plate wet disk Wet multi-disc Seat Suspension & Adjustability Deluxe suspension seat (high back, designed to absorb shock) Adjustable suspension seat (fore/aft, weight and height adjustment) Front Axle Type Not Published Four-wheel drive (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity 1,100 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 116.1 in 119 in Overall Width 53.7 in 66.4 in Wheelbase 66.7 in 66 in Ground Clearance 8.9 in Not Published Min. Turn Radius without Brakes 7.5 ft (with brake applied) 9.2 ft (with brake applied) Height to Top of ROPS 88.2 in 92.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 85.6 in Not Published ▶ WeightTractor Weight (Base) 2,191 lb Gear: 2,804 lb; HST: 2,870 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 180/85D12 7-14 R1 Agricultural - Rear 320/85D16 11.2-24 R3 Turf - Front 24x8.5-14 25x8.50-14 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front 23x8.5-12 or 25x8.5-14 25x8.50-14 R4 Industrial - Rear 14-17.5 or 15-19.5 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System LA545: 2-lever quick coupler, standard; Swift-Tach, optional Tool-free loader mount; optional skid-steer quick-attach plates Loader Model LA545 250TLA Loader Lift Height 87.6 in 250TLA: 104 in Loader Lift Capacity (Full Height) 1,100 lb 250TLA: 1,822 lb Loader Breakout Force Not Published 250TLA: 3,257 lb ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total)
