▶ EngineEngine Manufacturer Kubota Kubota Engine Model V1505-CR-TE5-D40R6 Not Published Engine Type Turbocharged, direct injection, liquid-cooled diesel Indirect injection, liquid-cooled diesel No. of Cylinders 4 3 Displacement 91.4 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2700 rpm Engine Power (Gross) 34.9 hp 35.7 hp PTO Power 29.6 hp F (2WD gear), DT (4WD gear): 30 hp; HST (4WD): 28.5 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Pressurized radiator Liquid-cooled Air Cleaner 6 in paper filter (with dual element) Not Published Fuel System Direct injection Indirect injection Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Dual pump Not Published Implement Flow Not Published 6.3 gpm Steering Flow Not Published 3.8 gpm Total Hydraulic Flow 9.1 gpm 10.1 gpm (6.3 + 3.8, computed) Overall Hydraulic Pump Flow 9.1 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None Not Published No. of Optional Remote Valves Optional, up to 2 Up to 3 ▶ Fluid CapacityFuel Tank Capacity 8.5 gal 9.0 gal Coolant Capacity Not Published Not Published Crankcase Capacity 5.0 qt Not Published Transmission / Hydraulic System Capacity 5.5 gal F (2WD): 7.1 gal; DT (4WD): 7.3 gal; HST (4WD): 6.2 gal Front Axle Fluid Capacity 4.8 qt 4.8 qt ▶ PTO & HitchPTO Type Independent F (2WD gear), DT (4WD gear): live-continuous running; HST (4WD): live-continuous with overrunning clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,348 lb 1,998 lb Hitch Lift Capacity (at 24”) 1,819 lb 1,435 lb Lift Control Type Position control valve Position control ▶ Transmission & DrivetrainTransmission Type Gear F (2WD gear), DT (4WD gear): sliding gear and constant mesh, 8F/4R; HST (4WD): hydrostatic transmission, 3-range No. of Speeds Not Published F (2WD gear), DT (4WD gear): 8F/4R; HST (4WD): 3-range Max Travel Speed (Forward) 14.7 mph F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph Max Travel Speed (Reverse) 14.6 mph F (2WD gear), DT (4WD gear): 4.7 mph; HST (4WD): 12.7 mph Clutch Dry type single stage F (2WD gear), DT (4WD gear): dry-type, dual-stage; HST (4WD): dry-type, single-stage Differential Lock & Limited Slip Options Standard Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Foldable ROPS (standard on all models) Steering Hydrostatic power steering Integral type power steering Brakes Multi-plate wet disk Wet disc type Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published 4WD: Bevel gear front axle Front Axle Rating Not Published Not Published Drawbar Capacity 1,100 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 39.4 in 51.4 in Wheelbase 61.0 in 63.3 in Ground Clearance 12.8 in F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.4 in Min. Turn Radius without Brakes 7.5 ft (with brake applied) F (2WD gear): 7.9 ft; DT (4WD gear), HST (4WD): 8.2 ft (with brake applied) Height to Top of ROPS 84.0 in 85.0 in Height to Top of ROPS (folded) 56.7 in Not Published Height to Top of Cab Model Not Applicable Not Published Overall Length 98.2 in (without 3-point hitch, with R1 tires) F (2WD gear): 110.6 in; DT (4WD gear), HST (4WD): 106.5 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 2,154 lb F (2WD gear): 2,403 lb; DT (4WD gear): 2,580 lb; HST (4WD): 2,600 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural AG standard; turf and industrial optional R1 Agricultural - Front 6-14 F (2WD gear): 5-15; DT (4WD gear), HST (4WD): 7-16 R1 Agricultural - Rear 8.3-24 11.2-24 R3 Turf - Front Not Published 25x8.50-14 (4WD) R3 Turf - Rear Not Published 13.6-16 R4 Industrial - Front Not Published 27x8.50-15 (4WD) R4 Industrial - Rear Not Published 15-19.5 R4 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Not Published LA463: quick attach/detach loader (mounting pins and hose couplers from the seat); skid steer-type quick coupler optional Loader Model Not Published LA463 Loader Lift Height Not Published LA463: 95.3 in (at pivot pin) Loader Lift Capacity (Full Height) Not Published LA463: 1,142 lb (at pivot pin) Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published
