▶ EngineEngine Manufacturer Kubota KIOTI Engine Model V1505-CR-TE5-D40Q3 3H-TH4D Engine Type Turbocharged, direct injection, liquid-cooled diesel 3-cylinder, liquid-cooled diesel No. of Cylinders 4 3 Displacement 91.4 in³ 111.4 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 39.8 hp 39.6 hp PTO Power 31.2 hp 29.1 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Pressurized radiator Liquid-cooled Air Cleaner 6 in paper filter (with dual element) Dry element Fuel System Direct injection Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Dual pump Gear Implement Flow 5.4 gpm 9.62 gpm Steering Flow 4.1 gpm 6.87 gpm Total Hydraulic Flow 9.5 gpm 16.5 gpm Overall Hydraulic Pump Flow 9.5 gpm 16.5 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None 2 No. of Optional Remote Valves Optional, up to 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 8.5 gal 12.7 gal Coolant Capacity 5.7 qt 2.1 gal Crankcase Capacity 5.0 qt 1.95 gal Transmission / Hydraulic System Capacity 5.5 gal 11.4 gal Front Axle Fluid Capacity 4.8 qt 1.48 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability 2460 rpm Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,535 lb 2,998 lb Hitch Lift Capacity (at 24”) 1,962 lb 2,716 lb Lift Control Type Position control valve Position ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission Hydrostatic (HST) No. of Speeds 3 ranges 3 ranges (hydrostatic, infinite speeds) Max Travel Speed (Forward) 17.0 mph 18.45 mph Max Travel Speed (Reverse) 13.0 mph 12.92 mph Clutch Not Published None (hydrostatic transmission) Differential Lock & Limited Slip Options Differential lock standard Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Multi-plate wet disk Wet multi-disc Seat Suspension & Adjustability Seat Type: Deluxe; Seat Suspension: Adjustable Deluxe suspension seat Front Axle Type Not Published Manual 4WD Front Axle Rating Not Published Not Published Drawbar Capacity 1,100 lb 1,655 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Width 53.7 in 62.8 in Wheelbase 66.7 in 71.3 in Ground Clearance 8.9 in 14.5 in Min. Turn Radius without Brakes 7.5 ft (with brake applied) 102.8 in (with brake applied) Height to Top of ROPS Not Published 96.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 85.6 in 93.0 in Overall Length 116.1 in (with 3-point hitch) 125.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,624 lb 3,523 lb (DK4220SEH); 4,043 lb (DK4220SEH CAB) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural - Front 180/85D12 8-16 R1 Agricultural - Rear 320/85D16 13.6-24 R3 Turf - Front 24X8.50-14 29-12.5-15 R3 Turf - Rear Not Published 21.5L-16.1 R4 Industrial - Front 23x8.5-14, 23x8.5-12 or 25x8.5-14 10-16.5 R4 Industrial - Rear 12.4-16, 14-17.5 or 15-19.5 14.9-24 ▶ Loader & AttachmentsQuick Attach Loader System LA545: 2-lever quick coupler, standard; Swift-Tach, optional Quick attach (QA) bucket, 66 in or 72 in Loader Model LA545 KL5520; KL5521 (Cab models) Loader Lift Height 87.6 in (at pivot pin) KL5520: 107.7 in; KL5521: 107.7 in Loader Lift Capacity (Full Height) 1,100 lb (at pivot pin) KL5520: 2,474 lb; KL5521: 2,474 lb Loader Breakout Force Not Published KL5520: 3,895 lb; KL5521: 3,895 lb ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Non-commercial: basic 24 months, unlimited hours, parts and labor, 0% deductible; powertrain 6 years, unlimited hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
