▶ EngineEngine Manufacturer Kubota Kubota Engine Model V1505-CR-TE5-D40Q3 V1903-A Engine Type Turbocharged, direct injection, liquid-cooled diesel Indirect injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 4 4 Displacement 91.4 in³ 113.3 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 39.8 hp 38.5 hp PTO Power 31.2 hp 31 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Pressurized radiator Water-cooled Air Cleaner 6 in paper filter (with dual element) Not Published Fuel System Direct injection Indirect injection Alternator Not Published Not Published ▶ HydraulicsPump Type Dual pump Not Published Implement Flow 5.4 gpm 7.8 gpm Steering Flow 4.1 gpm Not Published Total Hydraulic Flow 9.5 gpm Not Published Overall Hydraulic Pump Flow 9.5 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None Not Published No. of Optional Remote Valves Optional, up to 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 8.5 gal 9.2 gal Coolant Capacity 5.7 qt 7.9 qt Crankcase Capacity 5.0 qt 6.3 qt Transmission / Hydraulic System Capacity 5.5 gal 10.3 gal Front Axle Fluid Capacity 4.8 qt Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability 2460 rpm Optional mid-PTO, 2000 rpm (USA No. 5, Kubota 10-tooth involute spline) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,535 lb 2,870 lb Hitch Lift Capacity (at 24”) 1,962 lb 2,310 lb Lift Control Type Position control valve Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission F (2WD), DT (4WD): synchronized shuttle and synchronized transmission, 8F/8R; GST (4WD): Glide Shift, 8F/8R No. of Speeds 3 ranges 8F/8R Max Travel Speed (Forward) 17.0 mph 14.3 mph Max Travel Speed (Reverse) 13.0 mph 13.1 mph Clutch Not Published Dry type single stage Differential Lock & Limited Slip Options Differential lock standard Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post ROPS Steering Hydrostatic power steering Hydrostatic power steering Brakes Multi-plate wet disk Wet disc type Seat Suspension & Adjustability Seat Type: Deluxe; Seat Suspension: Adjustable Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,100 lb 1,430 lb ▶ Dimensions & ManeuverabilityOverall Width 53.7 in 56.1 in Wheelbase 66.7 in F (2WD): 71.3 in; DT (4WD), GST (4WD): 71.1 in Ground Clearance 8.9 in 13.2 in Min. Turn Radius without Brakes 7.5 ft (with brake applied) F (2WD), DT (4WD): 8.2 ft; GST (4WD): 8.5 ft (with brake applied) Height to Top of ROPS Not Published 83.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 85.6 in Not Published Overall Length 116.1 in (with 3-point hitch) 118.1 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 2,624 lb F (2WD): 2,800 lb; DT (4WD): 2,955 lb; GST (4WD): 2,965 lb (with ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial, R14 Ag: 6.00-16 (2WD) or 8.3-16 (4WD) front, 13.6-24 rear R1 Agricultural - Front 180/85D12 F (2WD): 6.00-16; DT (4WD), GST (4WD): 8.3-16 R1 Agricultural - Rear 320/85D16 13.6-24 R3 Turf - Front 24X8.50-14 Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 23x8.5-14, 23x8.5-12 or 25x8.5-14 Not Published R4 Industrial - Rear 12.4-16, 14-17.5 or 15-19.5 Not Published ▶ Loader & AttachmentsQuick Attach Loader System LA545: 2-lever quick coupler, standard; Swift-Tach, optional Not Published Loader Model LA545 LA680; LA681 Loader Lift Height 87.6 in (at pivot pin) LA680: 102.4 in; LA681: 102.4 in Loader Lift Capacity (Full Height) 1,100 lb (at pivot pin) LA680: 1,499 lb; LA681: 1,499 lb Loader Breakout Force Not Published LA680: 2,557 lbf; LA681: 2,557 lbf ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published
