▶ EngineEngine Manufacturer Kubota Kubota Engine Model V3307-CR-TE4 V2403-CR-E4-GL5 Engine Type 4-cylinder, turbocharged, common-rail diesel Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged No. of Cylinders 4 4 Displacement 203 in³ 148.5 in³ Rated Engine Speed 2400 rpm 2600 rpm Engine Power (Gross) 71.1 hp 62 hp PTO Power 60 hp 53 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dry paper, dual element Fuel System Common rail direct injection Electronic Common Rail System (CRS) Alternator 130 A 45 A, 12 V ▶ HydraulicsPump Type Not Published Tandem pump - gear type Implement Flow 16.7 gpm 9.4 gpm Steering Flow 6.3 gpm 4.7 gpm Total Hydraulic Flow 23.0 gpm (16.7 + 6.3, computed) 14.1 gpm Overall Hydraulic Pump Flow 23.0 gpm (16.7 + 6.3, computed) 14.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 (SCD) Not Published No. of Optional Remote Valves Max. 3 Optional, up to 3: double-acting valve or float detent valve, any position ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 13.5 gal Coolant Capacity 10.6 qt 8.7 qt Crankcase Capacity 12.7 qt 9.9 qt Transmission / Hydraulic System Capacity 49.6 qt 11.9 gal Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Live-independent PTO, electro-hydraulic clutch with brake Live independent (hydraulic clutch) PTO Rear 540 rpm (540/540E optional) 540 rpm @ 2400 engine rpm Mid-PTO Availability Not Published Optional Category, 3-Point Hitch Category I / II SAE Category I & II Hitch Lift Capacity Not Published 3,858 lb Hitch Lift Capacity (at 24”) 3,307 lb 2,976 lb Lift Control Type Position, draft (top link sensing) and mixed control Position control ▶ Transmission & DrivetrainTransmission Type Fully synchronized 6-speed main gear shift with electro-hydraulic shuttle, 12F/12R (option: 18F/18R with creep) Hydrostatic transmission No. of Speeds F12 / R12 (option: F18 / R18 with creep) 3-range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) Not Published 16.8 mph Max Travel Speed (Reverse) Not Published 15.2 mph Clutch Multiple wet disc Not Published Differential Lock & Limited Slip Options Front: limited-slip differential; Rear: mechanical differential lock Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Hydraulic wet disc Wet disc type, mechanically activated Seat Suspension & Adjustability Not Published Suspension seat with swivel function Front Axle Type Bevel gear type (4WD, mechanical on-the-go 4WD clutch) 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,433 lb ▶ Dimensions & ManeuverabilityOverall Width 75.6 in 67.3 in Wheelbase 84.1 in 75.4 in Ground Clearance 18.1 in (front axle crop clearance) 15.4 in Min. Turn Radius without Brakes 11.8 ft 9.2 ft (with brake applied) Height to Top of ROPS Not Published 98.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 101 in Not Applicable Overall Length 144 in 135.0 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 5,952 lb 3,990 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 320/70R24 front, 420/75R34 rear Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470) R1 Agricultural - Front 320/70R24 9.5-16 R1 Agricultural - Rear 420/75R34 14.9-26; 13.6-28 R3 Turf - Front 9.50-24 29X12.50-15 R3 Turf - Rear 18.4-26 44X18-20 R4 Industrial - Front 14-17.5 10-16.5 R4 Industrial - Rear 16.9-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Loader Model LA1154A LA1055 Loader Lift Height LA1154A: 133.0 in (height position); 117.6 in (power position) 112.7 in (at pivot pin) Loader Lift Capacity (Full Height) LA1154A: 2,674 lb (height position); 2,928 lb (power position) 2,361 lb (at pivot pin) Loader Breakout Force LA1154A: 4,079 lbf (height position); 5,128 lbf (power position) 3,171 lbf ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours, all usage Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
