▶ EngineEngine Manufacturer Kubota LS Mtron Engine Model V3307-CR-TE4 L4C25-T Engine Type 4-cylinder in-line, common rail direct injection, turbocharged diesel In-line vertical, water cooled 4-cycle diesel, CRDI No. of Cylinders 4 4 Displacement 203 in³ 152.9 in³ Rated Engine Speed 2400 rpm 2500 rpm Engine Power (Gross) 72.1 hp 73 hp PTO Power 60 hp 62 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Dry Fuel System Common rail direct injection Delphi, CRDI Alternator 130 A 70 A, 12 V ▶ HydraulicsPump Type Not Published Gear type, engine drive Implement Flow 16.7 gpm 13.2 gpm Steering Flow 6.3 gpm 6.6 gpm Total Hydraulic Flow 23.0 gpm (16.7 + 6.3, computed) 19.8 gpm Overall Hydraulic Pump Flow 23.0 gpm (16.7 + 6.3, computed) 19.8 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 (SCD) 3 Pairs (Front), 3 Pairs (Rear) No. of Optional Remote Valves Max. 3 Not Published ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 26.4 gal Coolant Capacity 10.6 qt 2.6 gal Crankcase Capacity 12.7 qt 2.1 gal Transmission / Hydraulic System Capacity 10.6 gal 14.5 gal Front Axle Fluid Capacity Not Published 1.5 gal ▶ PTO & HitchPTO Type Live-independent PTO, electro-hydraulic clutch with brake Independent PTO Rear 540 rpm (540/540E optional) 540 / 750 / 1,000 Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I / II Category II Hitch Lift Capacity Not Published 6,614 lb Hitch Lift Capacity (at 24”) 3307 lb 4,718 lb Lift Control Type Position, draft (top link sensing) and mixed control Position & Draft ▶ Transmission & DrivetrainTransmission Type Fully synchronized 6-speed main gear shift with electro-hydraulic shuttle, 12F/12R (option: 18F/18R with creep) MT573C: Synchro Shuttle; MT573CPS: Power Shuttle No. of Speeds F12 / R12 (option: F18 / R18 with creep) F20 x R20 Max Travel Speed (Forward) Not Published 19.4 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Multiple wet disc Wet clutch disks Differential Lock & Limited Slip Options Front: limited slip differential; Rear: mechanical differential lock Electro-hydraulic differential lock (EHD) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Brakes Hydraulic wet disc Not Published Seat Suspension & Adjustability Not Published Air suspension seat (10° swivel) Front Axle Type Bevel gear type (4WD, mechanical on-the-go 4WD clutch) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 142 in 150 in Overall Width 75.6 in 77.5 in Wheelbase 84.1 in 84.6 in Ground Clearance 18.1 in (front axle crop clearance) Not Published Min. Turn Radius without Brakes 11.8 ft 13.0 ft (4.0 m) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 101 in 104.4 in ▶ WeightTractor Weight (Base) 5952 lb MT573C: 6,620 lb; MT573CPS: 6,669 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 7,901 lb ▶ Tire OptionsTire Size & Options Standard: 320/85R20 front, 420/85R30 rear Ag 11.2-24 / 16.9-30; R14 W320/85R24 122D / W460/85R30 145D R1 Agricultural - Front 320/85R20 11.2-24 R1 Agricultural - Rear 420/85R30 16.9-30 R3 Turf - Front 9.50-24 Not Published R3 Turf - Rear 18.4-26 Not Published R4 Industrial - Front 14-17.5 Not Published R4 Industrial - Rear 16.9-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published LL6100: ISO 24410 “Quick Attachment” (Bobcat-type / skid-steer style; lever-lock with latch pins) Loader Model LA1154A LL6100 Loader Lift Height LA1154A: 133.0 in (height position); 117.6 in (power position) LL6100: 126.5 in Loader Lift Capacity (Full Height) LA1154A: 2674 lb (height position); 2928 lb (power position) LL6100: 3,626 lb Loader Breakout Force LA1154A: 4079 lbf (height position); 5128 lbf (power position) LL6100: 6,644 lb ▶ WarrantyWarranty Length & Coverage All usage - Basic Standard Limited: 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours. 6-year / 1,500-hour limited powertrain warranty; 2-year / 750-hour bumper-to-bumper warranty
