▶ EngineEngine Manufacturer Kubota FPT Engine Model V3307-CR-TE4 R753 Engine Type 4-cylinder, turbocharged, common-rail diesel Turbocharged, intercooled 3-cylinder diesel No. of Cylinders 4 3 Displacement 203 in³ 136 in³ Rated Engine Speed 2400 rpm 2600 rpm Engine Power (Gross) 71.1 hp 70 hp PTO Power 60 hp 62 hp Engine Emissions Constraints Not Published Tier 4B Final Cooling System Type Liquid-cooled Not Published Air Cleaner Not Published 2-stage Fuel System Common rail direct injection Common rail direct injection (CRDI) Alternator 130 A 75 A ▶ HydraulicsPump Type Not Published Dual hydraulic pumps; open center, fixed displacement gear pump Implement Flow 16.7 gpm 12 gpm Steering Flow 6.3 gpm 5.5 gpm Total Hydraulic Flow 23.0 gpm (16.7 + 6.3, computed) 17.5 gpm Overall Hydraulic Pump Flow 23.0 gpm (16.7 + 6.3, computed) 17.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 (SCD) 1 No. of Optional Remote Valves Max. 3 2 ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 17.2 gal Coolant Capacity 10.6 qt Not Published Crankcase Capacity 12.7 qt Not Published Transmission / Hydraulic System Capacity 49.6 qt Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Live-independent PTO, electro-hydraulic clutch with brake Independent PTO Rear 540 rpm (540/540E optional) 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I / II Category II/I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 3,307 lb 2,701 lb Lift Control Type Position, draft (top link sensing) and mixed control Position control with mechanical draft control ▶ Transmission & DrivetrainTransmission Type Fully synchronized 6-speed main gear shift with electro-hydraulic shuttle, 12F/12R (option: 18F/18R with creep) 8x8 synchronized shuttle No. of Speeds F12 / R12 (option: F18 / R18 with creep) 8F/8R Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Multiple wet disc Dry, 11 in organic plate Differential Lock & Limited Slip Options Front: limited-slip differential; Rear: mechanical differential lock Mechanical rear differential lock (foot pedal); 4WD front axle with limited slip and front differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Not Published Brakes Hydraulic wet disc Individual mechanically actuated wet disc Seat Suspension & Adjustability Not Published Deluxe contoured suspension seat, adjusts to operator height Front Axle Type Bevel gear type (4WD, mechanical on-the-go 4WD clutch) 4WD: limited-slip front axle with front differential lock, mechanical engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 75.6 in 67.5 in (shipping width) Wheelbase 84.1 in ROPS 4WD: 77.6 in Ground Clearance 18.1 in (front axle crop clearance) Not Published Min. Turn Radius without Brakes 11.8 ft Not Published Height to Top of ROPS Not Published ROPS 4WD: 97.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 101 in Not Applicable Overall Length 144 in ROPS 4WD: 134 in ▶ WeightTractor Weight (Base) 5,952 lb ROPS 2WD: 4,442 lb (shipping weight); ROPS 4WD: 5,059 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Applicable ▶ Tire OptionsTire Size & Options Standard: 320/70R24 front, 420/75R34 rear R1 agricultural, R3 turf, R4 industrial R1 Agricultural - Front 320/70R24 Not Published R1 Agricultural - Rear 420/75R34 14.9x28 R1 R3 Turf - Front 9.50-24 Not Published R3 Turf - Rear 18.4-26 Not Published R4 Industrial - Front 14-17.5 Not Published R4 Industrial - Rear 16.9-24 18.4x24 R4 ▶ Loader & AttachmentsQuick Attach Loader System Not Published 600TL Series quick-attach loader (611TL, 621TL, 616TL, 626TL) Loader Model LA1154A 611TL, 616TL, 621TL, 626TL (611TL and 621TL non self-leveling; 616TL and 626TL mechanical self-leveling) Loader Lift Height LA1154A: 133.0 in (height position); 117.6 in (power position) 611TL: 112 in; 616TL: 115 in; 621TL: 119 in; 626TL: 122 in Loader Lift Capacity (Full Height) LA1154A: 2,674 lb (height position); 2,928 lb (power position) Not Published Loader Breakout Force LA1154A: 4,079 lbf (height position); 5,128 lbf (power position) 611TL: 2,998 lb; 616TL: 3,130 lb; 621TL: 3,086 lb; 626TL: 3,527 lb (at 31.5 in in front of pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours, all usage Not Published
