▶ EngineEngine Manufacturer Kubota FPT Engine Model F2803 S8000 Engine Type Diesel, 5-cylinder, liquid-cooled 3-cylinder, FPT turbocharged & aftercooled diesel, Tier 4 B/Final No. of Cylinders 5 3 Displacement 167.6 in³ 178.8 in³ Rated Engine Speed 2600 rpm 2300 rpm Engine Power (Gross) 54 hp 54 hp PTO Power 45 hp 40 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual dry elements Not Published Fuel System Not Published Electronic high pressure common rail Alternator Not Published 120 A ▶ HydraulicsPump Type Not Published Fixed displacement Implement Flow Not Published 12.6 gpm Steering Flow Not Published Not Published Total Hydraulic Flow 17.1 gpm Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 to 3 2 No. of Optional Remote Valves Not Published 3 ▶ Fluid CapacityFuel Tank Capacity ROPS: 17.2 gal; Cab: 25.1 gal 21.7 gal Coolant Capacity 6.6 qt Not Published Crankcase Capacity 8.5 qt Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Live Independent PTO Rear 540 rpm 540 (standard); 540/540E (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II/I Category I/II Hitch Lift Capacity 4200 lb 5,952 lb (optional hitch 6,614 lb) Hitch Lift Capacity (at 24”) 3310 lb 4,300 lb (optional hitch 4,740 lb) Lift Control Type Position control and top-link draft sensing Mechanical Draft Control (MDC), top link sensing ▶ Transmission & DrivetrainTransmission Type 8-speed; 8-speed synchronized shuttle; 12-speed creeper MFD: 12x12 power shuttle (wet clutch); 2WD: 8x8 power shuttle (wet clutch); optional 12x12 mechanical shuttle (dry clutch) or 12x12 with creeper (20x20) No. of Speeds 8F/4R (12F/12R with creeper) MFD: 12F/12R; 2WD: 8F/8R; optional 12F/12R mechanical or 20F/20R creeper Max Travel Speed (Forward) Not Published 18.6 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published MFD: wet clutch (12x12 power shuttle); 2WD: wet clutch (8x8 power shuttle); optional dry clutch (12x12 mechanical shuttle) Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock; MFD engagement electrohydraulic; limited-slip MFD front axle ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Brakes Mechanical wet disc Wet disc Seat Suspension & Adjustability Not Published Mechanical contoured seat, adjustable; optional air-ride seat Front Axle Type Not Published 2WD or MFD with limited slip Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD ROPS: 137.6 in; 4WD ROPS: 134.1 in; 2WD cab: 140.6 in; 4WD cab: 137 in 155.3 in Overall Width 67.2 in (minimum) Not Published Wheelbase ROPS: 78.7 in; Cab: 81.7 in 2WD: 82.1 in; MFD: 83.6 in Ground Clearance 16.9 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 92.5 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 97.8 in 2WD: 98 in; MFD: 100 in ▶ WeightTractor Weight (Base) 2WD ROPS: 3748 lb; 4WD ROPS: 3968 lb 2WD Cab: 6,173 lb; 2WD Non-cab: 5,622 lb; MFD Cab: 6,834 lb; MFD Non-cab: 6,283 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 8.3-24 front (2WD and 4WD), 14.9-28 rear R-1 (ag tread) bias ply standard; optional R-1W (ag tread) radial R1 Agricultural - Front 8.3-24 2WD: 9.5L-15; MFD: 11.2x24 R1 Agricultural - Rear 14.9-28 2WD: 16.9R28; MFD: 16.9x30 (optional 16.9R28) R3 Turf - Front 2WD: 9.00-10; 4WD: 29x12.5-15 Not Published R3 Turf - Rear 21.5L-16.1 R3 Not Published R4 Industrial - Front 12.5/80-18 R4 Not Published R4 Industrial - Rear 16.9-24 R4 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model LA1002 L610 Loader Lift Height LA1002: 115.6 in 130.3 in Loader Lift Capacity (Full Height) LA1002: 2579 lb NSL: 1,828 lb; MSL: 3,153 lb Loader Breakout Force LA1002: 3330 lbf Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
