▶ EngineEngine Manufacturer Kubota Shibaura Engine Model F2803-ELA N4LDI-TA Engine Type Vertical, water-cooled, 4-cycle diesel, 5-cylinder 4-cylinder turbocharged intercooled diesel, liquid-cooled No. of Cylinders 5 4 Displacement 167.6 in³ 135.2 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 54 hp 53.9 hp PTO Power 45 hp Mech: 41.3 hp; HST: 39.7 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dual dry elements Dry Fuel System Not Published Common rail direct injection Alternator Not Published Not Published ▶ HydraulicsPump Type Not Published Engine-driven gear-type pump Implement Flow Not Published Not Published Steering Flow Not Published Not Published Total Hydraulic Flow 17.1 gpm Not Published Overall Hydraulic Pump Flow Not Published 12.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 12.1 gpm No. of Standard Remote Valves 1 Cab: 1 pair No. of Optional Remote Valves Not Published Up to 3 ▶ Fluid CapacityFuel Tank Capacity ROPS: 17.2 gal; Cab: 25.1 gal 14 gal Coolant Capacity 7.7 qt 7.08 qt Crankcase Capacity 8.5 qt 6.87 qt Transmission / Hydraulic System Capacity Not Published Power Shuttle: 10.04 gal; HST: 9.25 gal Front Axle Fluid Capacity Not Published 9 qt ▶ PTO & HitchPTO Type Live Independent, with soft-start feature PTO Rear 540 rpm 540 rpm (6-spline) Mid-PTO Availability Not Published Optional, 2,000 rpm Category, 3-Point Hitch Category II/I Category I with extendable ball ends Hitch Lift Capacity 4,200 lb Not Published Hitch Lift Capacity (at 24”) 3,307 lb 3,086 lb Lift Control Type Position, draft and mix control Draft control optional ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle, 8F/8R (12F/12R with creeper) 12 x 12 power shuttle or 3-range hydrostatic No. of Speeds 8F/8R (12F/12R with creeper) 12 x 12 Power Shuttle (3 ranges, 4 gears); HST: 3-range, infinite speeds in each range Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Single stage dry type Differential Lock & Limited Slip Options Not Published Mechanical engagement via right side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Mechanical wet disc Internal wet disc brakes, independent foot pedals Seat Suspension & Adjustability Not Published Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering Front Axle Type Not Published Cast-steel 4WD front axle, center driveline, bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 67.2 in (minimum) 65.4 in Wheelbase ROPS: 78.7 in; Cab: 81.7 in 77.9 in Ground Clearance 16.9 in 14.8 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 93.0 in 102.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 98.1 in 92.9 in Overall Length 2WD ROPS: 137.6 in; 4WD ROPS: 134.1 in; 2WD cab: 140.6 in; 4WD cab: 137.1 in 132.3 in ▶ WeightTractor Weight (Base) 2WD ROPS: 3,748 lb; 4WD ROPS: 3,968 lb 12x12 Power Shuttle: 3,968 lb (ROPS base weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 6.5-16 front (2WD), 9.5-22 front (4WD), 14.9-28 rear AG, Turf, Industrial, Snow R1 Agricultural - Front 8.3-24 9.5x16 R1 Agricultural - Rear 14.9-28 13.6x28 R3 Turf - Front 2WD: 9.00-10; 4WD: 29x12.5-15 27x10.50-15 R3 Turf - Rear 21.5L-16.1 R3 44x18.00-20 R4 Industrial - Front 12.5/80-18 R4 10-16.5 R4 Industrial - Rear 16.9-24 R4 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published DL135: Skid steer quick attach Loader Model LA1002 DL135 Loader Lift Height LA1002: 115.6 in DL135: 111 in (at pivot pin) Loader Lift Capacity (Full Height) LA1002: 2,579 lb (at pivot pin) DL135: 2,610 lb (at pivot pin, full height) Loader Breakout Force LA1002: 3,330 lbf DL135: 4,000 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Five-year powertrain warranty
