Kubota M4D-071 vs Kioti RX7320C | Side-by-side comparison | ITC Resource Center
Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
Live-independent PTO, electro-hydraulic clutch with brake
Independent
PTO Rear
540/540E rpm
540 / 540E rpm
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
I / II
Category II
Hitch Lift Capacity
4189 lb
4,974 lb
Hitch Lift Capacity (at 24”)
3307 lb
3,898 lb
Lift Control Type
Position, draft (top link sensing) & mixed control
Position, Draft, Mixed Control
Transmission Type
12-speed electro-hydraulic shuttle (option: 18-speed with creep)
Manual: Synchro Shuttle
No. of Speeds
F12/R12 (option: F18/R18 with creep)
12 forward / 12 reverse
Max Travel Speed (Forward)
24.9 mph
23.53 mph
Max Travel Speed (Reverse)
24.7 mph
23.13 mph
Clutch
Multiple wet disc
Dry Single Plate
Differential Lock & Limited Slip Options
Front limited slip differential; Rear differential lock (mechanical)
Rear differential lock (standard)
Frame Type
Ultra Grand Cab II
Not Published
Steering
Hydrostatic power steering
Hydrostatic Power Steering
Brakes
Hydraulic wet disc
Wet Multi Disc
Seat Suspension & Adjustability
Deluxe mechanical suspension seat with adjustable armrest, seat height, weight (suspension) and backrest tilt; optional air ride seat
Adjustable Seat
Front Axle Type
Bevel gear type (4WD)
Not Published
Front Axle Rating
Not Published
Not Published
Drawbar Capacity
2200 lb
Not Published
Overall Length with 3-Point Hitch
142 in
146.3 in
Overall Width
75.6 in
77.2 in
Wheelbase
84.1 in
83.9 in
Ground Clearance
18.1 in
17.3 in
Min. Turn Radius without Brakes
11.8 ft
11.2 ft (with brake applied)
Height to Top of ROPS
Not Published
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
101 in
104.5 in
Tractor Weight (Base)
6008 lb
6,162 lb
Weight with ROPS and Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Tire Size & Options
Standard: 320/70R24 front, 420/75R34 rear
R1 Agricultural, R4 Industrial
R1 Agricultural - Front
320/70R24
11.2-24
R1 Agricultural - Rear
420/75R34
16.9-30
R3 Turf - Front
9.50-24
Not Published
R3 Turf - Rear
18.4-26
Not Published
R4 Industrial - Front
14-17.5
12.5/80-18
R4 Industrial - Rear
16.9-24
18.4-24/8
Quick Attach Loader System
LA1154A: 2-Lever Quick Coupler
Built-in parking stand; designed to be quickly and easily attached and detached.
Loader Model
LA1154A
KL7320
Loader Lift Height
LA1154A: Height position: 133.0 in; Power position: 117.6 in
KL7320: 133.9 in (to pivot pin)
Loader Lift Capacity (Full Height)
LA1154A: Height position: 2674 lb; Power position: 2928 lb
KL7320: 3,384 lb (to full height at pivot pins)
Loader Breakout Force
LA1154A: Height position: 4079 lbf; Power position: 5128 lbf
KL7320: 5,359 lb (at pivot pins)
Warranty Length & Coverage
Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
Tractors (Non-Commercial Application): 24 months parts & labor; Extended (Non-Commercial, driveline/powertrain): 48 months parts & labor; Limited time: eligible units receive total 6 years (72 months) extended powertrain warranty coverage.
