▶ EngineEngine Manufacturer Kubota Yanmar Engine Model V3307-CR-TE4 4TN98CT-7PKTF Engine Type Liquid-cooled, diesel, 4-cylinder 4-cylinder, water-cooled, turbocharged diesel No. of Cylinders 4 4 Displacement 203 in³ 202.5 in³ Rated Engine Speed 2400 rpm 2400 rpm Engine Power (Gross) 71.1 hp 71.5 hp PTO Power 60 hp 60.2 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dual element (primary and secondary elements) PowerCore Type Fuel System Common Rail System (CRS) CRDI Alternator 130 A 70 A, 12 V ▶ HydraulicsPump Type Not Published Dual gear pump Implement Flow 16.7 gpm 10.3 gpm Steering Flow 6.3 gpm 5.8 gpm Total Hydraulic Flow 23.0 gpm (16.7 gpm implement + 6.3 gpm steering, computed) 16.1 gpm Overall Hydraulic Pump Flow 23.0 gpm (16.7 + 6.3, computed) 16.1 gpm Hydraulic System Type Open Center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (SCD / FD) Not Published No. of Optional Remote Valves Max. 3 Not Published ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 19 gal Coolant Capacity 10.6 qt 3 gal Crankcase Capacity 12.7 qt Not Published Transmission / Hydraulic System Capacity 49.6 qt 13.7 gal Front Axle Fluid Capacity 5.8 qt (front differential case) plus 3.7 qt (front axle gear case) 2.4 gal ▶ PTO & HitchPTO Type Live-independent PTO, electro-hydraulic clutch with brake Independent PTO Rear 540/540E rpm 540/750 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch I / II Category II Hitch Lift Capacity 4,189 lb 4,329 lb Hitch Lift Capacity (at 24”) 3,307 lb 3,159 lb Lift Control Type Position, draft (top link sensing) & mixed control Position/Draft ▶ Transmission & DrivetrainTransmission Type Fully synchronized 6-speed main gear shift with electro-hydraulic shuttle, 12F/12R (option: 18F/18R with creep) Power shuttle No. of Speeds F12/R12 (option: F18/R18 with creep) F12 x R12 Max Travel Speed (Forward) 24.9 mph 13.5 mph Max Travel Speed (Reverse) 24.7 mph Not Published Clutch Multiple wet disc Wet Multi Plate Differential Lock & Limited Slip Options Front: limited-slip differential; Rear: mechanical differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Ultra Grand Cab II Not Published Steering Hydrostatic power steering Hydrostatic Brakes Hydraulic wet disc Wet disc Seat Suspension & Adjustability Mechanical-suspension seat with adjustable armrest, seat height, weight (suspension) and backrest tilt; optional air-suspension seat Adjustable sliding seat with backrest angle and cushion firmness adjustment Front Axle Type Bevel gear type (4WD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 2,200 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 75.6 in 81.4 in Wheelbase 84.1 in 84.6 in Ground Clearance 18.1 in (front axle crop clearance) 17.6 in Min. Turn Radius without Brakes 11.8 ft 164.2 in; 169.3 in Height to Top of ROPS Not Published 106.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 101 in Not Published Overall Length 144 in 148.1 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 6,008 lb 5,463 lb (with ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 320/70R24 front, 420/75R34 rear Not Published R1 Agricultural - Front 320/70R24 11.2-24 R1 Agricultural - Rear 420/75R34 16.9-30 R3 Turf - Front 9.50-24 Not Published R3 Turf - Rear 18.4-26 Not Published R4 Industrial - Front 14-17.5 15-19.5 R4 Industrial - Rear 16.9-24 18.4-24 ▶ Loader & AttachmentsQuick Attach Loader System LA1154A: 2-Lever Quick Coupler Not Published Loader Model LA1154A L5074SL Loader Lift Height LA1154A: Height position: 133.0 in; Power position: 117.6 in Not Published Loader Lift Capacity (Full Height) LA1154A: Height position: 2,674 lb; Power position: 2,928 lb Not Published Loader Breakout Force LA1154A: Height position: 4,079 lbf; Power position: 5,128 lbf Not Published ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Basic 24 months or 2,000 hours, parts and labor; loaders, backhoes and mid-mount mowers 12 months
