▶ EngineEngine Manufacturer Kubota KIOTI Engine Model V3800CR-TIEF4 4J243TA-TP5B Engine Type 4-cylinder, turbocharged and intercooled, common-rail diesel, DPF, DOC and SCR 4-cylinder, in-line vertical, water-cooled, turbocharged and intercooled CRDI diesel (4J243TA-TP5B) No. of Cylinders 4 4 Displacement 230 in³ 233.9 in³ Rated Engine Speed 2400 rpm 2200 rpm Engine Power (Gross) 92.5 hp 90 hp PTO Power 76 hp 70 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry paper, dual element, 8 in diameter, with pre-cleaner Dry element with evacuator valve Fuel System Common rail direct injection CRDI Alternator 60 A Not Published ▶ HydraulicsPump Type Gear pump Gear Implement Flow 15.9 gpm 19.8 gpm Steering Flow 5.4 gpm 12.2 gpm Total Hydraulic Flow 21.3 gpm 32 gpm Overall Hydraulic Pump Flow 21.3 gpm 32 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow 15.7 gpm Not Published No. of Standard Remote Valves 2 standard (3 maximum) 3 No. of Optional Remote Valves Not Published 4th remote valve ▶ Fluid CapacityFuel Tank Capacity 27.7 gal 47.6 gal Coolant Capacity 11 qt 4.6 gal Crankcase Capacity 11.3 qt 3.9 gal Transmission / Hydraulic System Capacity 63.4 qt 20.34 gal Front Axle Fluid Capacity 6.3 qt (differential) plus 3.7 qt (each bevel gear case) 2.6 gal ▶ PTO & HitchPTO Type Live-independent PTO, electro-hydraulic clutch with brake Independent PTO Rear 540 rpm (540/540E on 12-speed models) 540 / 540E / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 7,055 lb 8,079 lb Hitch Lift Capacity (at 24”) 4,630 lb (8-speed); 6,063 lb (12-speed) 8,002 lb Lift Control Type Position, draft (top link sensing) and mixed control Electronic control ▶ Transmission & DrivetrainTransmission Type Fully synchronized main gear shift with electro-hydraulic shuttle Power Shuttle w/ Hi-Lo Shift No. of Speeds 8 forward, 8 reverse (8-speed models); 12 forward, 12 reverse (12-speed models) 24 forward / 24 reverse Max Travel Speed (Forward) 17.7 mph (8-speed); 22.6 mph (12-speed) 23.83 mph Max Travel Speed (Reverse) 8-speed: 18.4 mph; 12-speed: 23.5 mph 23.67 mph Clutch Multiple wet disc Wet Multi Disc Differential Lock & Limited Slip Options Front: limited-slip differential; Rear: mechanical differential lock Mechanical rear differential lock (standard); front limited-slip differential ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Hydraulic wet disc Wet Disc Seat Suspension & Adjustability Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest Heated air suspension seat, 20 degree swivel both directions, adjustable fore/aft Front Axle Type Bevel gear type with 55 degree turning angle (4WD) 4WD, outboard planetary drives, limited-slip differential Front Axle Rating 5,730 lb Not Published Drawbar Capacity 3,300 lb Max. Drawbar vertical load: 3,307 lb; Max. Trailer loading weight: 9,921 lb ▶ Dimensions & ManeuverabilityOverall Width 78.3 in 88.6 in Wheelbase 88.6 in 94.9 in Ground Clearance 17.7 in (minimum, drawbar bracket) 18.9 in Min. Turn Radius without Brakes 13.8 ft 12.7 ft (with brake applied) Height to Top of ROPS 98.9 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable 111.9 in Overall Length 155.9 in 170.8 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 6,151 lb 10,230 lb (with AG tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 R1 Agricultural (bias 13.6-24 / 18.4-34, radial 13.6R-24 / 18.4R-34); R14 radial (340/85R24 / 460/85R34) R1 Agricultural - Front 11.2-24 13.6-24 R1 Agricultural - Rear 18.4-30 18.4-34 R3 Turf - Front 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) Not Published R3 Turf - Rear 18.4-26 R3 or 19.5L-24 R3 Not Published R4 Industrial - Front 9.5L-15 F2 (rib front paired with the R4 rear) Not Published R4 Industrial - Rear 19.5L-24 R4 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Quick coupler, standard; Euro-type quick coupler, optional; tool-free attach and detach; single-lever hydraulic hose coupler, optional KL1155: quick-attach system with built-in parking stand; single-lever joystick control with float; bucket level indicator Loader Model LA1854 KL1155 Loader Lift Height 145.7 in (height position); 131.9 in (power position) KL1155: 150.6 in (to pivot pin) Loader Lift Capacity (Full Height) 3,990 lb (height position); 4,144 lb (power position) KL1155: 4,216 lb (at pivot pins) Loader Breakout Force LA1854: 5,501 lb at bucket pivot pin (height position); 6,470 lb at bucket pivot pin (power position) KL1155: 8,554 lb (at pivot pins) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Non-commercial: basic 24 months, unlimited hours, parts and labor, 0% deductible; powertrain 48 months, unlimited hours, HX series
