▶ EngineEngine Manufacturer Kubota AGCO Power Engine Model V3800CR-TIEF4 Not Published Engine Type 4-cylinder in-line, common rail direct injection, turbocharged with intercooler, DPF, DOC and SCR diesel 3-cylinder, intercooled turbocharged diesel No. of Cylinders 4 3 Displacement 230 in³ 201 in³ Rated Engine Speed 2600 rpm 2200 rpm Engine Power (Gross) 92.5 hp 95 hp PTO Power 76 hp 77 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry paper, dual element, 8 in diameter, with pre-cleaner Dual element (primary and secondary) Fuel System Common rail direct injection High-pressure common rail direct fuel injection Alternator 80 A, 12 V 80 A ▶ HydraulicsPump Type Gear pump Two-stage pump Implement Flow 17.0 gpm Not Published Steering Flow 6.1 gpm Not Published Total Hydraulic Flow 23.1 gpm Not Published Overall Hydraulic Pump Flow 23.1 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 17.0 gpm 17.2 gpm No. of Standard Remote Valves 1 standard (3 maximum) 2 No. of Optional Remote Valves 2 optional (3 maximum) 1 ▶ Fluid CapacityFuel Tank Capacity 27.7 gal 33 gal Coolant Capacity 11 qt 4.2 gal Crankcase Capacity 11.3 qt 3.3 gal Transmission / Hydraulic System Capacity 15.9 gal Power Shuttle: 10.6 to 11.4 gal; Mechanical: 8.5 to 9.2 gal Front Axle Fluid Capacity 6.3 qt (differential) plus 3.7 qt (each bevel gear case) Dana: 1.45 gal beam plus 0.24 gal per final drive; Carraro: 1.3 gal beam plus 0.21 gal per final drive ▶ PTO & HitchPTO Type Live-independent PTO, electro-hydraulic clutch with brake Independent, electrohydraulic engagement PTO Rear 540 rpm (540/540E optional) 540/540E standard; 540/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 7055 lb (8860 lb optional) Not Published Hitch Lift Capacity (at 24”) 5181 lb 4,850 lb Lift Control Type Position, draft (top link sensing) and mixed control Not Published ▶ Transmission & DrivetrainTransmission Type Fully synchronized main gear shift with electro-hydraulic shuttle 12x12 fully synchronized power shuttle, 6 gears x 2 ranges, electrohydraulic shuttle lever; optional Dyna-2 24x24 powershift No. of Speeds 8 forward, 8 reverse 12 forward and 12 reverse; 24 forward and 24 reverse with optional Dyna-2 Max Travel Speed (Forward) 18.6 mph 25 mph Max Travel Speed (Reverse) 18.4 mph Not Published Clutch Multiple wet disc Multidisc wet clutch with easy shift knob and electrohydraulic power shuttle lever Differential Lock & Limited Slip Options Limited slip differential (front); mechanical differential lock (rear) Hydraulic with electronic control, rear axle engaged via electrohydraulic rocker switch; 4WD front axle Hydra-Lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Cab: tilt and telescopic steering column; Platform: tilt steering column Brakes Hydraulic wet disc Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Seat Suspension & Adjustability Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest Cab: mechanical swiveling seat with armrests, air-ride swivel seat optional; Platform: mechanical spring suspension seat with armrests Front Axle Type Bevel gear type with 55 degree turning angle (4WD) Heavy-duty 2WD or 4WD front axle Front Axle Rating 5730 lb Not Published Drawbar Capacity 3300 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 155.9 in Not Published Overall Width 78.3 in 60.3 in (minimum, with std. 420/85R30 rear tires) Wheelbase 88.6 in 88.5 in Ground Clearance 18.7 in Not Published Min. Turn Radius without Brakes 13.8 ft Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100.2 in Not Published ▶ WeightTractor Weight (Base) 6900 lb 2WD ROPS: 7,478 lb; 2WD Cab: 8,294 lb; 4WD ROPS: 7,734 lb; 4WD Cab: 8,644 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 2WD: 9.5L-15 front, 420/85R30 rear; 4WD: 320/85R24 front, 420/85R30 rear R1 Agricultural - Front 11.2-24 2WD: 9.5L-15; 4WD: 320/85R24 R1 Agricultural - Rear 18.4-28 420/85R30 R3 Turf - Front 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) Not Published R3 Turf - Rear 18.4-26 R3 or 19.5L-24 R3 Not Published R4 Industrial - Front 9.5L-15 F2 (rib front paired with the R4 rear) Not Published R4 Industrial - Rear 19.5L-24 R4 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Quick coupler standard (Euro type optional); quick-mount loader attach and detach without tools; single-lever hydraulic hose quick coupler optional 931X and 936X: universal skid steer type quick release Loader Model LA1854 FL.3522, FL.3615, 931X, 936X Loader Lift Height 145.7 in (height position); 131.9 in (power position) FL.3522: 140 in; FL.3615: 140 in; 931X: 136 in; 936X: 136 in (at pivot pin) Loader Lift Capacity (Full Height) 3990 lb (height position); 4144 lb (power position) FL.3522: 2,760 lb; FL.3615: 3,420 lb; 931X: 2,140 lb; 936X: 3,340 lb (to full height, at 31.5 in forward of pivot pin) Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage All Usage - Basic Standard Limited: 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours. Not Published
