▶ EngineEngine Manufacturer Kubota KIOTI (Daedong) Engine Model V3800CR-TIEF4 4J243TA-TP5B Engine Type 4-cylinder in-line, common rail direct injection, turbocharged with intercooler, DPF, DOC and SCR diesel In-Line Vertical, Water-cooled 4-Cycle Turbo Diesel, CRDI (4J243TA-TP5B) No. of Cylinders 4 4 Displacement 230 in³ 233.9 in³ Rated Engine Speed 2400 rpm 2200 rpm Engine Power (Gross) 92.5 hp 90 hp PTO Power 76 hp 70 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry paper, dual element, 8 in diameter, with pre-cleaner Dry element with evacuator valve Fuel System Common rail direct injection Common Rail Direct Injection (CRDI) Alternator 60 A, 12 V Not Published ▶ HydraulicsPump Type Gear pump Gear Implement Flow 15.9 gpm 19.8 gpm Steering Flow 5.4 gpm 12.2 gpm Total Hydraulic Flow 21.3 gpm 32 gpm Overall Hydraulic Pump Flow 21.3 gpm 32 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow 15.7 gpm Not Published No. of Standard Remote Valves 1 standard (3 maximum) 3 No. of Optional Remote Valves 2 optional (3 maximum) 1 ▶ Fluid CapacityFuel Tank Capacity 27.7 gal 47.6 gal Coolant Capacity 11 qt 4.6 gal Crankcase Capacity 11.3 qt 3.9 gal Transmission / Hydraulic System Capacity 15.9 gal 20.34 gal Front Axle Fluid Capacity Not Published 2.6 gal ▶ PTO & HitchPTO Type Live-independent PTO, electro-hydraulic clutch with brake Independent PTO Rear 540 rpm (540/540E optional) 540 / 540E / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 7055 lb (8860 lb optional) 8,079 lb Hitch Lift Capacity (at 24”) 5181 lb 8,002 lb Lift Control Type Position, draft (top link sensing) and mixed control Electronic control ▶ Transmission & DrivetrainTransmission Type Fully synchronized main gear shift with electro-hydraulic shuttle Power Shuttle w/ Hi-Lo Shift No. of Speeds 8 forward, 8 reverse 24 forward / 24 reverse Max Travel Speed (Forward) 17.7 mph 23.83 mph Max Travel Speed (Reverse) 17.6 mph 23.67 mph Clutch Multiple wet disc Wet Multi Disc Differential Lock & Limited Slip Options Mechanical differential lock (rear) Mechanical rear differential lock (standard); front limited-slip differential ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Hydraulic wet disc Wet Multi Disc Seat Suspension & Adjustability Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest Heated air suspension seat, 20 degree swivel both directions, adjustable fore/aft Front Axle Type Adjustable tubular steel 4WD with outboard planetary final drives and limited-slip differential Front Axle Rating 4850 lb Not Published Drawbar Capacity 3300 lb Max. Drawbar vertical load: 3,307 lb; Max. Trailer loading weight: 9,921 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 156.0 in 170.8 in Overall Width 77.2 in 88.6 in Wheelbase 90.0 in 94.9 in Ground Clearance 20.5 in 18.9 in Min. Turn Radius without Brakes 12.1 ft 12.7 ft (with brake applied) Height to Top of ROPS 98.8 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 111.9 in ▶ WeightTractor Weight (Base) 5622 lb 10,230 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 7.50-18, 9.5L-15, 10.00-16; Rear: 16.9-30, 16.9-34, 18.4-30 R1 Agricultural (bias 13.6-24 / 18.4-34, radial 13.6R-24 / 18.4R-34); R14 radial (340/85R24 / 460/85R34) R1 Agricultural - Front 7.5-18 13.6-24 R1 Agricultural - Rear 18.4-28 18.4-34 R3 Turf - Front 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) Not Published R3 Turf - Rear 18.4-26 R3 or 19.5L-24 R3 Not Published R4 Industrial - Front 9.5L-15 F2 (rib front paired with the R4 rear) Not Published R4 Industrial - Rear 19.5L-24 R4 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Quick coupler standard (Euro type optional); quick-mount loader attach and detach without tools; single-lever hydraulic hose quick coupler optional KL1155: quick-attach system with built-in parking stand; single-lever joystick control with float; bucket level indicator Loader Model LA1854 KL1155 Loader Lift Height 145.7 in (height position); 131.9 in (power position) KL1155: 150.6 in (to pivot pin) Loader Lift Capacity (Full Height) 3990 lb (height position); 4144 lb (power position) KL1155: 4,216 lb (at pivot pins) Loader Breakout Force Not Published KL1155: 8,554 lb (at pivot pins) ▶ WarrantyWarranty Length & Coverage All Usage - Basic Standard Limited: 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours. Tractors (Non-Commercial): 24 months parts & labor, unlimited hours, 0% deductible; powertrain (engine and driveline): 48 months unlimited hours on HX Series
