▶ EnginePTO Power n/a 19.2 (14.3) HP (kW) Alternator n/a 40 A Air Cleaner n/a Dual paper element Engine Type n/a E-TVCS, liquid cooled, 3-cylinder diesel Fuel System n/a Radial air flow Displacement n/a 68.5 (1123) cu. in. (cc) No. of Cylinders n/a 3 Rated Engine Speed n/a 2600 rpm Cooling System Type n/a Liquid Cooled Engine Manufacturer n/a Kubota Engine Power (Gross) n/a 21.9 (16.3) HP (kW) Engine Emissions Constraints n/a Tier 4 ▶ WeightTractor Weight (Base) n/a 1,404 lbs. Weight with ROPS and Loader n/a 1,521 lbs. ▶ WarrantyWarranty Length & Coverage n/a Full warranty: 2 years / 2,000 hours; Powertrain warranty: 6 years / 2,000 hours ▶ HydraulicsPump Type n/a Dual pump Steering Flow n/a 2.6 gpm 9.8 lpm Implement Flow n/a 4.0 gpm Total Hydraulic Flow n/a 7.0 (26.4) gpm (ℓ/min.) Hydraulic System Type n/a Open center System Operating Pressure n/a 2500 psi Rear Remote Hydraulic Flow n/a Front & Rear outlet Overall Hydraulic Pump Flow n/a 7.0 (26.4) gpm (ℓ/min.) No. of Optional Remote Valves n/a 1 No. of Standard Remote Valves n/a 0 ▶ PTO & HitchPTO Rear n/a 540, 1000 rpm PTO Type n/a Transmission driven with one way clutch Lift Control Type n/a Position control valve Hitch Lift Capacity n/a 1653 (750) lbs. (kg) Mid-PTO Availability n/a 2500 rpm Category, 3-Point Hitch n/a Category I Hitch Lift Capacity (at 24”) n/a 1808 (820) lbs. (kg); 1411 (640) lbs. (kg); 1290 (585) lbs. (kg) ▶ Tire OptionsR3 Turf - Rear n/a 33x12.5-15 R3 Turf - Front n/a 23x8.50-12 R1 Agricultural - Rear n/a 9.5-16 R1 Agricultural - Front n/a 6-12 ▶ Fluid CapacityCoolant Capacity n/a 4.0 (3.8) qts. (ℓ) Crankcase Capacity n/a 3.3 (3.1) qts. (ℓ) Fuel Tank Capacity n/a 6.1 gal. Transmission / Hydraulic System Capacity n/a 3.3 (12.5) gal (ℓ) ▶ Loader & AttachmentsLoader Lift Height n/a 78.5" Loader Breakout Force n/a 2,146 lbf. Quick Attach Loader System n/a LA435 Swift-Tach Loader; 1-lever Quick Coupler (standard); 2-Lever Quick Coupler (optional) Loader Lift Capacity (Full Height) n/a 1,175 lbs. ▶ Transmission & DrivetrainClutch n/a Dry single plate No. of Speeds n/a 9 Forward, 3 Reverse Transmission Type n/a Gear (9 Forward, 3 Reverse) Max Travel Speed (Forward) n/a 0-11.7 (0-18.8) mph (km/h) Max Travel Speed (Reverse) n/a 0-6.0 (0-9.6) mph (km/h) Differential Lock & Limited Slip Options n/a Standard ▶ Chassis, Steering & ControlsBrakes n/a Multi-plate wet disc Steering n/a Integral type power steering Front Axle Type n/a Cast-iron front axle Drawbar Capacity n/a 661.4 lb (660 lbs) Seat Suspension & Adjustability n/a High-back seat (absorbs shock); NOTE: Deluxe seat with armrests and seat suspension listed for HST models only - not explicitly confirmed for B2401 gear-drive (DT) in spec sheet ▶ Dimensions & ManeuverabilityWheelbase n/a 61.4 (1560) in. (mm) Overall Width n/a 44.3 (1125) in. (mm) Overall Length n/a 93.9 in / 93.9 in Ground Clearance n/a 12.0 (305) in. (mm) Height to Top of ROPS n/a 83.9 in. Min. Turn Radius without Brakes n/a 6.9 (2.1) feet (m) Overall Length with 3-Point Hitch n/a 93.9 in. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
