▶ EngineEngine Manufacturer Kubota Kubota Engine Model V3800CR-TIEF4 V3800CR-TIEF4 Engine Type 4-cylinder, turbocharged and intercooled, common-rail diesel, DPF, DOC and SCR 4-cylinder, turbocharged and intercooled, common-rail diesel, DPF, DOC and SCR No. of Cylinders 4 4 Displacement 230 in³ 230 in³ Rated Engine Speed 2400 rpm 2400 rpm Engine Power (Gross) 105.6 hp 92.5 hp PTO Power 89 hp 76 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry paper, dual element, 8 in diameter, with pre-cleaner Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System Common rail direct injection Common rail direct injection Alternator 60 A 60 A ▶ HydraulicsPump Type Gear pump Gear pump Implement Flow 15.7 gpm 15.9 gpm Steering Flow 5.4 gpm 5.4 gpm Total Hydraulic Flow 21.3 gpm 21.3 gpm Overall Hydraulic Pump Flow 21.3 gpm 21.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 15.7 gpm 15.7 gpm No. of Standard Remote Valves 2 (max 3) 2 standard (3 maximum) No. of Optional Remote Valves 1 (3 maximum) Not Published ▶ Fluid CapacityFuel Tank Capacity 27.7 gal 27.7 gal Coolant Capacity 11 qt 11 qt Crankcase Capacity 11.3 qt 11.3 qt Transmission / Hydraulic System Capacity 63.4 qt 63.4 qt Front Axle Fluid Capacity 6.3 qt (differential) plus 3.7 qt (each bevel gear case) 6.3 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type Live-independent PTO, electro-hydraulic clutch with brake Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 rpm (540/540E optional) 540 rpm (540/540E on 12-speed models) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 7,055 lb (8,600 lb optional) 7,055 lb Hitch Lift Capacity (at 24”) 5,181 lb 4,630 lb (8-speed); 6,063 lb (12-speed) Lift Control Type Position, draft (top link sensing) and mixed control Position, draft (top link sensing) and mixed control ▶ Transmission & DrivetrainTransmission Type Fully synchronized main gear shift with electro-hydraulic shuttle Fully synchronized main gear shift with electro-hydraulic shuttle No. of Speeds 8 forward, 8 reverse 8 forward, 8 reverse (8-speed models); 12 forward, 12 reverse (12-speed models) Max Travel Speed (Forward) 18.6 mph 17.7 mph (8-speed); 22.6 mph (12-speed) Max Travel Speed (Reverse) 18.4 mph 8-speed: 18.4 mph; 12-speed: 23.5 mph Clutch Multiple wet disc Multiple wet disc Differential Lock & Limited Slip Options Front: limited-slip differential; Rear: mechanical differential lock Front: limited-slip differential; Rear: mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Hydraulic wet disc Hydraulic wet disc Seat Suspension & Adjustability Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest Front Axle Type Bevel gear type with 55 degree turning angle (4WD) Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating 5,730 lb 5,730 lb Drawbar Capacity 3,300 lb 3,300 lb ▶ Dimensions & ManeuverabilityOverall Width 79.1 in 78.3 in Wheelbase 88.6 in 88.6 in Ground Clearance 17.7 in (drawbar bracket) 17.7 in (minimum, drawbar bracket) Min. Turn Radius without Brakes 13.8 ft 13.8 ft Height to Top of ROPS 99.8 in 98.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable Not Applicable Overall Length 155.9 in 155.9 in ▶ WeightTractor Weight (Base) 6,283 lb 6,151 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 R1 Agricultural - Front 12.4-24 11.2-24 R1 Agricultural - Rear 18.4-30 18.4-30 R3 Turf - Front 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) R3 Turf - Rear 18.4-26 R3 or 19.5L-24 R3 18.4-26 R3 or 19.5L-24 R3 R4 Industrial - Front 9.5L-15 F2 (rib front paired with the R4 rear) 9.5L-15 F2 (rib front paired with the R4 rear) R4 Industrial - Rear 19.5L-24 R4 19.5L-24 R4 ▶ Loader & AttachmentsQuick Attach Loader System Quick coupler, standard; Euro-type quick coupler, optional; tool-free attach and detach; single-lever hydraulic hose coupler, optional Quick coupler, standard; Euro-type quick coupler, optional; tool-free attach and detach; single-lever hydraulic hose coupler, optional Loader Model LA1854 LA1854 Loader Lift Height 145.7 in (height position); 131.9 in (power position) 145.7 in (height position); 131.9 in (power position) Loader Lift Capacity (Full Height) 3,990 lb (height position); 4,144 lb (power position) 3,990 lb (height position); 4,144 lb (power position) Loader Breakout Force LA1854: 5,501 lbf (height position); 6,470 lbf (power position) LA1854: 5,501 lb at bucket pivot pin (height position); 6,470 lb at bucket pivot pin (power position) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours
