▶ EngineEngine Manufacturer Kubota Kubota Engine Model V3800CR-TIEF4 V3800CR-TIEF4 Engine Type 4-cylinder in-line, common rail direct injection, turbocharged with intercooler, DPF, DOC and SCR diesel 4-cylinder in-line, common rail direct injection, turbocharged with intercooler, DPF, DOC and SCR diesel No. of Cylinders 4 4 Displacement 230 in³ 230 in³ Rated Engine Speed 2600 rpm 2400 rpm Engine Power (Gross) 105.6 hp 105.6 hp PTO Power 89 hp 89 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry paper, dual element, 8 in diameter, with pre-cleaner Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System Common rail direct injection Common rail direct injection Alternator 80 A, 12 V 60 A, 12 V ▶ HydraulicsPump Type Gear pump Gear pump Implement Flow 17.0 gpm 15.9 gpm Steering Flow 6.1 gpm 5.4 gpm Total Hydraulic Flow 23.1 gpm 21.3 gpm Overall Hydraulic Pump Flow 23.1 gpm 21.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 15.9 gpm 15.9 gpm No. of Standard Remote Valves 1 standard (3 maximum) 1 standard (3 maximum) No. of Optional Remote Valves 2 optional (3 maximum) 2 optional (3 maximum) ▶ Fluid CapacityFuel Tank Capacity 27.7 gal 27.7 gal Coolant Capacity 11 qt 11 qt Crankcase Capacity 11.3 qt 11.3 qt Transmission / Hydraulic System Capacity 15.9 gal 15.9 gal Front Axle Fluid Capacity 6.3 qt (differential) plus 3.7 qt (each bevel gear case) 6.3 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type Live-independent PTO, electro-hydraulic clutch with brake Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 rpm (540/540E optional) 540 rpm (540/540E on 12-speed models) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 7055 lb (8860 lb optional) 7055 lb (8860 lb optional) Hitch Lift Capacity (at 24”) 5181 lb 5181 lb (8-speed); 7275 lb (12- and 24-speed) Lift Control Type Position, draft (top link sensing) and mixed control Position, draft (top link sensing) and mixed control ▶ Transmission & DrivetrainTransmission Type Fully synchronized main gear shift with electro-hydraulic shuttle Fully synchronized main gear shift with electro-hydraulic shuttle (Hi-Lo dual speed on HDC24) No. of Speeds 8 forward, 8 reverse 8 forward, 8 reverse (8-speed models); 12 forward, 12 reverse (12-speed models); 24 forward, 24 reverse (HDC24) Max Travel Speed (Forward) 18.6 mph 18.6 mph (8-speed); 23.6 mph (12-speed); 23.4 mph (24-speed) Max Travel Speed (Reverse) 18.4 mph 18.4 mph (8-speed); 23.5 mph (12-speed) Clutch Multiple wet disc Multiple wet disc Differential Lock & Limited Slip Options Limited slip differential (front); mechanical differential lock (rear) Limited slip differential (front); mechanical differential lock (rear) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Hydraulic wet disc Hydraulic wet disc Seat Suspension & Adjustability Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest Front Axle Type Bevel gear type with 55 degree turning angle (4WD) Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating 5730 lb 5730 lb Drawbar Capacity 3300 lb 3300 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 155.9 in 155.9 in Overall Width 79.1 in 79.1 in Wheelbase 88.6 in 88.6 in Ground Clearance 19.7 in 19.7 in Min. Turn Radius without Brakes 13.8 ft 13.8 ft Height to Top of ROPS Not Published 99.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 101.2 in 101.2 in ▶ WeightTractor Weight (Base) 7033 lb 6173 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 R1 Agricultural - Front 12.4-24 12.4-24 R1 Agricultural - Rear 18.4-30 18.4-30 R3 Turf - Front 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) R3 Turf - Rear 18.4-26 R3 or 19.5L-24 R3 18.4-26 R3 or 19.5L-24 R3 R4 Industrial - Front 9.5L-15 F2 (rib front paired with the R4 rear) 9.5L-15 F2 (rib front paired with the R4 rear) R4 Industrial - Rear 19.5L-24 R4 19.5L-24 R4 ▶ Loader & AttachmentsQuick Attach Loader System Quick coupler standard (Euro type optional); quick-mount loader attach and detach without tools; single-lever hydraulic hose quick coupler optional Quick coupler standard (Euro type optional); quick-mount loader attach and detach without tools; single-lever hydraulic hose quick coupler optional Loader Model LA1854 LA1854 Loader Lift Height 145.7 in (height position); 131.9 in (power position) 145.7 in (height position); 131.9 in (power position) Loader Lift Capacity (Full Height) 3990 lb (height position); 4144 lb (power position) 3990 lb (height position); 4144 lb (power position) Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage All Usage - Basic Standard Limited: 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours. 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours.
