▶ EngineEngine Manufacturer Kubota AGCO Power Engine Model V3800CR-TIEF4 Not Published Engine Type 4-cylinder in-line, common rail direct injection, turbocharged with intercooler, DPF, DOC and SCR diesel 4-cylinder, intercooled turbocharged, liquid-cooled diesel No. of Cylinders 4 4 Displacement 230 in³ 268.5 in³ Rated Engine Speed 2600 rpm 2200 rpm Engine Power (Gross) 105.6 hp 110 hp PTO Power 89 hp Power Shuttle: 93 hp; Dyna-4: 86 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry paper, dual element, 8 in diameter, with pre-cleaner Not Published Fuel System Common rail direct injection High-pressure common-rail direct injection (HPCR) Alternator 80 A, 12 V 120 A, 12 V ▶ HydraulicsPump Type Gear pump Two high-pressure gear pumps Implement Flow 17.0 gpm 15.1 gpm Steering Flow 6.1 gpm Not Published Total Hydraulic Flow 23.1 gpm 25.9 gpm Overall Hydraulic Pump Flow 23.1 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 15.9 gpm 26 gpm No. of Standard Remote Valves 1 standard (3 maximum) 2 No. of Optional Remote Valves 2 optional (3 maximum) 1 ▶ Fluid CapacityFuel Tank Capacity 27.7 gal 38.3 gal Coolant Capacity 11 qt Not Published Crankcase Capacity 11.3 qt Not Published Transmission / Hydraulic System Capacity 15.9 gal Not Published Front Axle Fluid Capacity 6.3 qt (differential) plus 3.7 qt (each bevel gear case) Not Published ▶ PTO & HitchPTO Type Live-independent PTO, electro-hydraulic clutch with brake Independent, electro-hydraulic engagement via switch PTO Rear 540 rpm (540/540E optional) 540 / 540E / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 7055 lb (8860 lb optional) Not Published Hitch Lift Capacity (at 24”) 5181 lb 7,710 lb Lift Control Type Position, draft (top link sensing) and mixed control Electronic linkage control (ELC) ▶ Transmission & DrivetrainTransmission Type Fully synchronized main gear shift with electro-hydraulic shuttle Power Shuttle: 12F x 12R, 2-range with electrohydraulic shuttle lever; Dyna-4: 16F x 16R powershift No. of Speeds 8 forward, 8 reverse Power Shuttle: 12 forward, 12 reverse; Dyna-4: 16 forward, 16 reverse Max Travel Speed (Forward) 18.6 mph 25 mph Max Travel Speed (Reverse) 18.4 mph Not Published Clutch Multiple wet disc Single-plate wet clutch with easy shift knob and electrohydraulic power shuttle lever Differential Lock & Limited Slip Options Limited slip differential (front); mechanical differential lock (rear) Rear differential lock engaged via electrohydraulic rocker switch; Hydra-Lock hydraulic front axle differential lock on 4WD ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering; cab: tilt and telescopic column, platform: tilt column Brakes Hydraulic wet disc Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Seat Suspension & Adjustability Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest Cab: air-ride swivel seat; platform: mechanical spring suspension seat with armrests Front Axle Type Bevel gear type with 55 degree turning angle (4WD) Heavy-duty 4WD front axle: cast steel, fixed, center drive line, planetary final drives Front Axle Rating 5730 lb Not Published Drawbar Capacity 3300 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 155.9 in Not Published Overall Width 79.1 in 64.8 in Wheelbase 88.6 in 95.7 in Ground Clearance 19.7 in Not Published Min. Turn Radius without Brakes 13.8 ft Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 101.2 in Not Published ▶ WeightTractor Weight (Base) 7033 lb 4WD ROPS: 9,195 lb; 4WD Cab: 10,011 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 Rear: 460/85R34 standard radial R1 Agricultural - Front 12.4-24 Not Published R1 Agricultural - Rear 18.4-30 Not Published R3 Turf - Front 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) Not Published R3 Turf - Rear 18.4-26 R3 or 19.5L-24 R3 Not Published R4 Industrial - Front 9.5L-15 F2 (rib front paired with the R4 rear) Not Published R4 Industrial - Rear 19.5L-24 R4 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Quick coupler standard (Euro type optional); quick-mount loader attach and detach without tools; single-lever hydraulic hose quick coupler optional Not Published Loader Model LA1854 941X; 946X; FL.3723; FL.3819 Loader Lift Height 145.7 in (height position); 131.9 in (power position) 941X: 148 in; 946X: 148 in; FL.3723: 149 in; FL.3819: 149 in Loader Lift Capacity (Full Height) 3990 lb (height position); 4144 lb (power position) 941X: 3,650 lb; FL.3723: 4,519.5 lb Loader Breakout Force Not Published FL.3723: 5,818.6 lb; FL.3819: 4,892.9 lb ▶ WarrantyWarranty Length & Coverage All Usage - Basic Standard Limited: 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours. Not Published
