▶ EngineEngine Manufacturer Kubota FPT Engine Model V3800CR-TIEF4 F5G Engine Type 4-cylinder, turbocharged and intercooled, common-rail diesel, DPF, DOC and SCR Dual Command: 4-cylinder diesel; Electro Command: turbo diesel with high-pressure common rail and electronic fuel delivery control No. of Cylinders 4 4 Displacement 230 in³ 207 in³ Rated Engine Speed 2400 rpm 2200 rpm Engine Power (Gross) 105.6 hp 107 hp PTO Power 89 hp 93 hp Engine Emissions Constraints Tier 4 Tier 4B Final Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry paper, dual element, 8 in diameter, with pre-cleaner Not Published Fuel System Common rail direct injection Electro Command: high-pressure common-rail, electronic fuel delivery control Alternator 60 A 120 A ▶ HydraulicsPump Type Gear pump Fixed displacement, tandem pumps (implement and steering) Implement Flow 15.7 gpm Dual Command: 16.9 gpm; Electro Command: 21.1 gpm Steering Flow 5.4 gpm Dual Command: 9.7 gpm; Electro Command: 11.4 gpm Total Hydraulic Flow 21.3 gpm Dual Command: 26.6 gpm (16.9 + 9.7, computed); Electro Command: 32.5 gpm (21.1 + 11.4, computed) Overall Hydraulic Pump Flow 21.3 gpm Dual Command: 26.6 gpm (16.9 + 9.7, computed); Electro Command: 32.5 gpm (21.1 + 11.4, computed) Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow 15.7 gpm Not Published No. of Standard Remote Valves Not Published Dual Command: 2 or 3; Electro Command: 2 No. of Optional Remote Valves Not Published Electro Command: 3 rear remotes (mechanical, 2 with configurable detents) ▶ Fluid CapacityFuel Tank Capacity 27.7 gal Electro Command: 43.6 gal Coolant Capacity 11 qt Not Published Crankcase Capacity 11.3 qt Not Published Transmission / Hydraulic System Capacity 63.4 qt Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Live-independent PTO, electro-hydraulic clutch with brake Independent (hydraulic wet disc clutch) PTO Rear 540 rpm (540/540E optional) Dual Command: 540/1000 rpm (optional); Electro Command: 540/1000 rpm (540/540E/1000 optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 7,055 lb (8,600 lb optional) Not Published Hitch Lift Capacity (at 24”) 5,181 lb Dual Command: 5,620 lb (7,351 lb with optional ram) Lift Control Type Position, draft (top link sensing) and mixed control Not Published ▶ Transmission & DrivetrainTransmission Type Fully synchronized main gear shift with electro-hydraulic shuttle Dual Command: 24x24 Hi-Lo with power shuttle (standard); Electro Command: 16x16 semi-powershift (auto-shift or 32x32 creeper optional) No. of Speeds 8 forward, 8 reverse Dual Command: 24F/24R; Electro Command: 16F/16R (32F/32R with creeper) Max Travel Speed (Forward) 18.6 mph 25 mph Max Travel Speed (Reverse) 18.4 mph Not Published Clutch Multiple wet disc Not Published Differential Lock & Limited Slip Options Mechanical differential lock (rear) Optional TerraLock automatic 4WD engagement and differential lock system (Electro Command) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Hydraulic wet disc Hydraulic wet disc Seat Suspension & Adjustability Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest Not Published Front Axle Type Adjustable tubular steel Electro Command: 4WD front axle, Class 1.5 HD (TerraGlide suspended 4WD front axle optional) Front Axle Rating 4,850 lb Not Published Drawbar Capacity 3,300 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 78.3 in Dual Command: 75.7 in Wheelbase 90.0 in Dual Command: 89.9 in; Electro Command: 93.7 in Ground Clearance 17.7 in (drawbar bracket) Not Published Min. Turn Radius without Brakes 12.1 ft Not Published Height to Top of ROPS 99.8 in Dual Command: 106.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Dual Command: 102.1 in; Electro Command: 107 in Overall Length 156.5 in Dual Command: 160.9 in; Electro Command: 165 in ▶ WeightTractor Weight (Base) 5,865 lb Dual Command (ROPS): 7,672 lb; Dual Command (Cab): 8,157 lb; Electro Command (Cab): 10,031 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 7.50-18, 9.5L-15, 10.00-16; Rear: 16.9-30, 16.9-34, 18.4-30 Not Published R1 Agricultural - Front 7.5-18 14.9R24 R1 Agricultural - Rear 18.4-30 18.4R34 R3 Turf - Front 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) Not Published R3 Turf - Rear 18.4-26 R3 or 19.5L-24 R3 Not Published R4 Industrial - Front 9.5L-15 F2 (rib front paired with the R4 rear) Not Published R4 Industrial - Rear 19.5L-24 R4 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Quick coupler, standard; Euro-type quick coupler, optional; tool-free attach and detach; single-lever hydraulic hose coupler, optional Skid-steer style or Euro (European) style tool carrier Loader Model LA1854 810LA (NSL); 815LA (MSL) Loader Lift Height 145.7 in (height position); 131.9 in (power position) 825TL: 139.0 in; 835TL: 146.9 in (to pivot pin) Loader Lift Capacity (Full Height) 3,990 lb (height position); 4,144 lb (power position) 825TL NSL: 2,954 lb; 825TL MSL: 3,086 lb; 835TL NSL: 3,638 lb; 835TL MSL: 3,836 lb (to max height, measured 31.5 in forward of pivot pin) Loader Breakout Force LA1854: 5,501 lbf (height position); 6,470 lbf (power position) 825TL NSL: 3,109 lb; 825TL MSL: 3,417 lb; 835TL NSL: 3,880 lb; 835TL MSL: 4,277 lb (measured 31.5 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Not Published
